EN
USER'S GUIDE.
Display
Radio receiver „activ" indication / Slow-or speed charge
mode „active" indication / „low battery" indication in
combination with ProPac battery pac.
Modeling Lamp
On (prop x)-Off
Modeling Light „Auto-Off" indication
Modeling Lamp 100% On-Off
Modeling Light „Auto-Off" indication/
„slow-charge" Mode activation/ deactivation
Test button
Activates radio trigger
Output setting
Radio trigger channel and ID selection
Sync socket
Thank you for choosing MULTIBLITZ, we hope you enjoy working with this
high quality product. MULTIBLITZ flash units are designed and manufactured
without exception in Germany.
CAUTION!
Please read the instruction manual carefully before using this product. Flash-/ and
halogen tubes as well as metal parts can become very hot during operation and may
cause burns if not properly handled.
Opening the unit could be extremely dangerous! Do not open the unit by yourself!
Service should only be executed by an authorized MULTIBLITZ service location.
Do not obstruct the venting slots. Do not place filters, diffusing materials, or any
other obstructions directly onto the flash-/ and halogen tubes. Do not expose the
unit to water (spray-/ or dripping water).
Do not run the X-10AC/DC unit with gasoline or diesel generators. Use exclusively
with Multiblitz battery packs or mains voltage.
8
This unit should be serviced once a year by an authorized MULTIBLITZ service
location.
The crossed out wheeled bin label that can be found on your product indicates that
this product should not be disposed of via the normal household waste stream.
To prevent possible harm to the environment or human health please
separate this product from other waste streams to ensure that it can
be recycled in an environ mentally sound manner. For more details on
available collection facilities please contact your local government of-
fice or the retailer where you purchased this product.
In order to avoid excessive concentration of ozone produced by using strong flash
devices, it is necessary to ventilate confined spaces regularly.
The minimum distance of 0.5m to the illuminated area must be
strictly maintained.
Protection glases has to be replaced in case of damage.
IR/Photo Slave cell
IR/ Photo Slave cell On-Off
Activates Pre-Flash Eliminator,
Pre-Flash Eliminator „active" indication
Beep/Lamp
Ready Indicator
ID Selection, in combination with radio trigger
Power On-Off
„speed mode"
indication
Fuse holder/
Spare fuse
