LD Systems WSECO2 Bedienungsanleitung Seite 14

HANDHELD TRANSMITTER:
7
14
1
2
4
3
5
6
MICROPHONE HEAD
1
With dynamic microphone capsule.
GAIN
2
Setting the microphone volume. Turning the knob to the right
increases the volume and turning it to the left decreases it.
LDWSECO2: Adjust the sensitivity so that when a signal is pre-
sent (voice, vocals, guitar...), the green signal LED (NORM) on the
receiver lights up. As soon as the red PEAK LED lights up, reduce
the level accordingly, otherwise undesirable distortion may occur.
LDWSECO2X2: Adjust the sensitivity so that when a signal is
present (voice, vocals, guitar...), the green signal LED (NORM)
on the receiver lights up. Once the audio signal begins to
distort, reduce the level accordingly.
RF POWER H / L
3
For a majority of applications, set the switch to H (= high
power). To increase battery life, switch to L (= low power)
for applications with a small distance between transmitter
and receiver. Before the event, please check whether the low
transmission power is sufficient.
BATTERY COMPARTMENT
4
Insert two 1.5 V AA size alkaline batteries (LR6 Mignon) as in the
illustration inside the battery compartment. If the transmitter is
not in use for a long period of time, remove the batteries from
the battery compartment.
BATT LED
5
As soon as the red LED lights up to indicate battery status,
replace the batteries immediately.
6 ON/OFF SWITCH
When the transmitter is turned on, the red LED flashes briefly
to indicate the battery status and goes out immediately if
batteries with sufficient charge are inserted.
BATTERY REPLACEMENT
7
As soon as the red LED lights up for battery status display,
please replace the batteries by unscrewing the battery cover
counter-clockwise from the transmitter and after changing the
batteries screw it back on in the opposite direction.
