IMPORTANT SAFETY INSTRUCTIONS T h i s s y m b o l i n d i c a t e s d a n g e r o u s v o l t a g e i n s i d e t h e p r o d u c t t h a t p r e s e n t s a r i s k o f e l e c t r i c s h o c k o r p e r s o n a l i n j u r y.
Seite 3
IMPORTANT SAFETY INSTRUCTIONS Do not place the LCD TV/monitor on an unstable cart, stand, tripod, bracket, table, or floor where it can fall. It is damaged if dropped, hit or scratched. Do not clean the front with keton-type materials (e.g.Acetone ),ethyl alcohol, toluene, ethy lacid, methyl, or chloride-these may damage the panel.
Seite 4
CONTENT PANEL BUTTON FUNCTIONS Front panel Local keyboard panel EXTERNAL EQUIPMENT Connecting diagram REMOTE CONTROL Remote control Remote buttons(DVD mode option) 7 Battery installation Remote buttons (TV mode option) LET S START Switching on Selecting source operation TV OSD MANUAL First Time installation TV Information Video menu options...
PANEL BUTTON FUNCTIONS FRONT PANEL Indicator (the indicator is red when in standby mode, and green when in working normally). IR sensor window LOCAL KEYBOARD PANEL (VERSIONS) TV+DVD (15,6“, 19“) TV+DVD (22“) TV/AV NEXT PLAY\ II PREV EJECT TV/AV STOP VOL+ PLAY\ II VOL-...
Seite 8
REMOTE CONTROL REMOTE BUTTONS TV mode option 1. AUTO Reserved. 2. MUTE Sound mute switch. 3. NUMBER BUTTONS Select program number. RECALL) Swap between a previous program and the current program. 5. NICAM Display program sound information, select NICAM sound channel. 6.
Seite 9
REMOTE CONTROL REMOTE BUTTONS 23. STANDBY Switch between standby mode and power-on mode. 24. -/- - To toggle one-two digits channel number entering mode. 25. ASPECT Change picture dimensions ratio in sequence: FullScreen, Zoom1, Zoom2, Auto, 4:3, 14:9, 16:9, Subtitle. 26.
Seite 11
REMOTE CONTROL REMOTE BUTTONS DVD mode option (EJECT) Disk in/out. 42.DVD SETUP Display DVD setup menu. (PLAY/PAUSE) Play or pause of playing. (STOP) Stop of playing. (SLOW MOTION) Different speeds of playing in sequent. (PREVIOUS) Play to the last Title / Chapter / Track. (NEXT) Play to the next Title / Chapter / Track.
REMOTE CONTROL BATTERY INSTALLATION Remove the battery cover. Insert two SUM-4(AAA) batteries matching the -/+ polarities of the battery to the -/+ marks inside the battery compartment, as follows: BATTERY LIFE Normally, battery can be used one year. If the remote control is still invalid when very near to the TV's remote sensor window, please use new battery.
Seite 13
LET S START After the unit has been suitably placed / fixed, on the desk or on the wall, and all necessary cables include power have connected, the next you should do is: • Press the [STANDBY] button on the remote control to make the unit switch to power-on mode - you will see the LED indicator turn green.
OSD MANUAL First Time Installation If this is the first time you open the TV and there is no France programs in the TV memory, the First Time Installation English menu will appear in the picture. Cancel Country Press button and then use to select the country.
Seite 17
OSD MANUAL VIDEO menu options Press MENU button on the front panel or LCD-MENU on the remote control to display the main menu. 1. Press ◄ / ► button to select PICTURE in the main menu. 2. Press ▼ / ▲ button to select the option that you want to adjust in the PICTURE menu.
Seite 18
OSD MANUAL AUDIO menu options 1. Press the ◄ / ► button to select SOUND in the main menu. 2. Press the ▼ / ▲ button to select the option that you want to adjust in the SOUND menu. 3. Press the ◄ / ► button to adjust. 4.
Seite 19
OSD MANUAL 1. Press the ◄ / ► button to select SETUP in the main menu. 2. Press the ▼ / ▲ button to select your option what you want to adjust in the SETUP menu. 3. Press the ◄ / ► button to adjust. 4.
Seite 20
OSD MANUAL Colour System Press ◄ / ► to select a corresponding colour system, such as Auto, PAL, SECAM. Program Label This option allows you to label a channel, you can also relabel the programs have been labeled. 1. Select a channel you want to labeled. 2.
OSD MANUAL Timer menu options Press MENU button on the front panel or LCD-MENU on the remote control to display the main menu. 1. Press the ◄ / ► button to select TIMER in the main menu. 2. Press the ▼ / ▲ button to select your option what you want to adjust in the TIMER menu.
Seite 23
OSD MANUAL Blue screen This option allows you to select the blue background on or off. If on, the screen background will turn blue at very weak or no signal condition. Child Lock Press ENTER or button to set the child lock. ►...
Seite 24
OSD MANUAL Hotel Lock Hotel Lock LOCK SETTING Hotel Lock Source Lock Default Source Default Prog Max Volume Clear Lock Press the button to select your option what you want to adjust in the LOCK SETTING menu. Press the button to adjust. When you are satisfied with your adjustment, press the LCD-MENU button to return to the previous menu or press the EXIT button to exit the main menu.
Seite 25
OSD MANUAL Default Source Press to select the default source from TV, SCART, CVBS, S-VIDEO, VGA, HDMI or DVD. Default Prog Press to select the default program in Hotel mode. Max Volume Press to adjust the max volume in Hotel mode. Clear Lock Press to clear the lock settings in Hotel mode.
TELETEXT FUNCTION TELETEXT FUNCTION Most TV stations provide cost-free teletext information, including the latest news, weather information, TV program list and stock information etc. You just input the needed teletext page according to the teletext content. TELETEXT MODES DISPLAY • Select the channel with teletext signal;...
Seite 30
DVD OPERATION NOTE: From track 1-10, use numeric buttons directly; For tracks over 10, press - / -- button first. (E.g. Track 15, press -/--, then 5) .DISP...
Seite 31
DVD OPERATION (2 pages), .DISP Press .DISP button again to display second pages shown below: .DISP .DISP .DISP .DISP .DISP...
Seite 33
DVD OPERATION NOTE: In Setup mode, the following functions will be cancel or pause :...
Seite 34
DVD OPERATION - Playback screen size may vary according to the discs contents. - For discs with 4:3 contents, using any mode would only display a 4:3 screen - Screen ratio selection should be according to the connected TV / Display aspect ratio.
Seite 35
DVD OPERATION 0000 NOTE: Only editable when password is unlocked. And only can function when password is locked. It does not, however, reset either the Password or the Rating setting.
Seite 36
DVD OPERATION - OSD Language NOTE: If the selected language is not included in you DVD disc content, it will select the default language of the disc automatically. The default language setting is ENGLISH. - Audio Language NOTE: If the selected language is not included in you DVD disc content, it will select the default language of the disc automatically.
TROUBLESHOOTING Please check for causes of problems in accordance with the following chart before contacting any maintenance personnel. DISPLAY TROUBLESHOOTING Causes and Correction Symptom Check whether power cord is well connected, and whether this unit is power on Black screen, power indicator light off Check whether the signal cord of input device is well connected...
Seite 40
SPECIFICATIONS Size 15" : 38 cm / 19" : 48 cm / 22" : 56 cm LCD Screen Type TFT colour Built in DVD Video and Audio input Connector 15": 1280 x 800 / 19": 1440 x 900 / 22": 1680 x 1050 STEREO NICAM / A2 DVD VIDEO / MPEG4 / SVCD / VCD1.0, 1.1, 2.0 version / CD-DA...
Seite 45
LCD-TFT LCD1521TNDVX LCD1921TNDVX LCD1922TNDVX LCD2221TNDVX GEBRUIKERSHANDLEIDING (NL) ZORGVULDIG DOORLEZEN VOOR GEBRUIK...
Seite 46
BELANGRIJKE VEILIGSHEIDSINSTRUCTIES Dit symbool geeft aan dat dit produkt gevaarlijke voltage heeft wat een risiko is voor elektrische shock of persoonlijke blessures. Dit symbool geeft aan dat belangrijke instructies aan het produkt zijn bijgevoegd. Gelieve deze handleiding voor het gebruik zorgvuldig door te lezen. •...
Seite 47
BELANGRIJKE VEILIGSHEIDSINSTRUCTIES • Plaats de LCD TV/monitor niet op een instabiele wagen, stand, driepoot, plankdrager, tafel of bodem waar het kan vallen. Indien het valt, een slag krijgt of gekrast wordt, is het beschadigd. Maak de voorkant niet schoon met keton-type materialen (zoals aceton), ethyl alcohol, toluene, ethyl lacid, methyl of chloride-these, deze kunnen het paneel beschadigen.
INHOUD PANEEL KNOPPEN FUNCTIES Voorkant paneel Lokaal toetsenbord paneel EXTERN MATERIAAL Diagram aansluiten AFSTANDSBEDIENING Afstandsknoppen (TV modus optie) Afstandsbediening Afstandsknoppen (DVD modus optie) Plaatsen van de batterijen HET BEGIN Aanzetten Bron gebruik uitkiezen TV OSD HANDLEIDING Eersteinstallatie TVinformatie Video menu opties Audio menu opties Setup menu opties VGA / HDMI ingang...
PANEEL KNOPPEN FUNCTIES VOORKANT PANEEL Indicator (de indicator wordt rood in standby modus en groen als de TV aan is). IR sensor opening LOKAAL TOETSENBORD PANEEL (VERSIES) TV+DVD (15,6“, 19“) TV+DVD (22“) VOLGENDE TV/AV PLAY\ II VORIGE EJECT STOP TV/AV VOL+ PLAY\ II VOL-...
AFSTANDSBEDIENING AFSTANDSKNOPPEN modus optie 1. AUTO Gereserveerd. 2. MUTE Zet het geluid uit. 3. NUMMER KNOPPEN Kiest het programma nummer. RECALL) Wisselt tussen het vorige en het huidige programma. 5. NICAM Geeft de geluidsinformatie van het programma weer, kies hiervoor het NICAM geluidskanaal.
Seite 53
AFSTANDSBEDIENING 23. STANDBY Schakelt tussen standby en aan modus. 24. -/- - Wisselt naar de modus om een kanaalnummer met twee getallen in te geven. 25. ASPECT Wijzigt de beeld dimensie-ratio als volgt: Full screen, Zoom 1, Zoom 2, Auto, 4:3, 14:9, 16:9, Ondertiteling.
AFSTANDSBEDIENING AFSTANDSKNOPPEN DVD modus optie (EJECT) Disc in/uit. 42. DVD SETUP Toont het DVD instellingen menu. (PLAY/PAUZE) Afspelen of het afspelen pauzeren. (STOP) Stopt het afspelen. (SLOWMOTION) Verschillende snelheden bij het afspelen. (VORIGE) Spoel naar het laatste titel / hoofdstuk / nummer. (VOLGENDE) Spoel naar het volgende titel / hoofdstuk / nummer.
AFSTANDSBEDIENING PLAATSEN VAN DE BATTERIJEN Open het batterij deksel. Plaats twee SUM-4 (AAA) batterijen zoals de polariteit het aangeeft, waarbij de + van de batterij bij de – van het batterij-kompartiment hoort, zoals hier: LEVENSDUUR BATTERIJ • Normaal gesproken kan de batterij het een heel jaar doen. •...
HET BEGIN Nadat het apparaat korrekt geplaatst is, op het onderstel of aan de wand, en alle noodzakelijke kabels inclusief het netsnoer aangesloten zijn, moet u het volgende doen: • Druk op de [STANDBY] knop op de afstandsbediening om het apparaat aan te zetten – u zult zien dat de LED indicator groen wordt.
OSD HANDLEIDING Eerste installatie Eerste keer installeren Land Overig Taal Hollands Als dit de eerste keer is dat u uw TV gebruikt en er geen Verwijderen Programma programma’s in het geheugen van de TV zijn, verschijnt Programma zoeken het Eerste keer installeren menu in uw beeld. Annuleren Selecteer Land...
Seite 60
OSD HANDLEIDING TV informatie Programma informatie Druk op de DISPLAY of NICAM knoppen om de programma informatie weer te geven. Geen signaal 1. Het nummer van het huidige programma. 2. Het kleursysteem van het huidige programma, kan geselecteerd worden in het Hand afstemmen menu (een optie in het SET-UP menu).
OSD HANDLEIDING VIDEO menu opties Druk op de MENU knop aan de voorkant van het paneel of op LCD-MENU op de afstandsbediening om het hoofdmenu weer te geven. 1. Druk op de knop om BEELD in het hoofdmenu te kiezen. BEELD 2.
OSD HANDLEIDING AUDIO menu opties Druk op de MENU knop aan de voorkant van het paneel of op LCD-MENU op de afstandsbediening om het hoofdmenu weer te geven. 1. Druk op de knop om GELUID in het hoofdmenu te kiezen. GELUID 2.
Seite 63
OSD HANDLEIDING 1. Druk op de knop om SET-UP in het hoofdmenu te kiezen. 2. Druk op de knop om de optie die u wilt aanpassen in het SET-UP menu te kiezen. 3. Druk op de knop om aan te passen. 4.
Seite 64
OSD HANDLEIDING Kleur systeem Druk op om een bijbehoren kleursysteem te kiezen, zoals Auto, PAL, SECAM. Programma Label Deze optie laat u een kanaal een naam geven, maar u kunt ook de reeds benoemde programma’s een andere naam geven. 1. Kies het kanaal wat u wilt benoemen. 2.
Seite 65
OSD HANDLEIDING VGA ingang SETUP menu van VGA ingang (voor het instellen van de PC beeld positie): MODUS Synchr Beginnen Fase Klok Positie Positie Reset positie Selecteer Enter HDMI ingang SETUP menu van HDMI ingang (voor het instellen van de HDMI beeld positie): MODUS Positie Positie...
OSD HANDLEIDING Timer menu opties Druk op de MENU knop aan de voorkant van het paneel of op LCD-MENU op de afstandsbediening om het hoofdmenu weer te geven. 1. Druk op de knop om TIMER in het hoofdmenu te kiezen. 2.
Seite 67
OSD HANDLEIDING Blauw scherm Deze optie laat u kiezen of de blauwe achtergrond aan of uit moet. Indien aan, zal de achtergrond van het scherm blauw worden bij een zwak signaal of geen signaalontvangst. Kinderslot Druk op ENTER of knop om de kinderblokkade in te stellen. U moet de PIN code invoeren als de kinderblokkade “aan”...
Seite 68
OSD HANDLEIDING Nieuwe PIN code Druk op de 0-9 toetsen om de nieuwe PIN code in te voeren. Wijzig PIN code Druk op de 0-9 toetsen om de PIN code die u heeft ingevoerd in het Nieuwe PIN Code menu nogmaals in om de nieuwe PIN code te bevestigen.
Seite 69
OSD HANDLEIDING Standaard Bron Druk op om bij de standaard bron te kiezen uit TV, SCART, CVBS, S-VIDEO, VGA, HDMI of DVD. Standaard Progr Druk op om het standaard programma in Hotel modus te kiezen. Maximum- Volume Druk op om het maximale volume in Hotel modus aan te passen. Sluiting opheffen Druk op om de blokkade instellingen in Hotel modus vrij te geven.
TELETEXT FUNCTIE TELETEXT FUNCTIE De meeste TV zenders bieden gratis teletext informatie, inclusief het laatste nieuws, weerberichten, TV programma’s en beurzeninformatie, etc. U hoeft enkel de gewenste teletext pagina in te voeren om de bijbehorende inhoud te lezen. TELETEXT MODUS DISPLAY •...
DVD GEBRUIK Basis gebruik 1. De DVD functie AAN en UIT zetten - Zet de LCD TV aan en druk dan op de INPUT knop op RC. Gebruik de knoppen om de DVD modus te kiezen en bevestig dit met de ENTER knop.
Seite 73
DVD GEBRUIK DVD/ MP3/JPEG discs Super VCD/ VCD/ CD /CD-G/ D-CD discs --:-- 5--:-- 9--:-- 13--:-- ----- 5----- 9----- 13----- 2--:-- 6--:-- 10--:-- 14--:-- 2----- 6----- 10----- 14----- 3--:-- 7--:-- 11--:-- 15--:-- 3----- 7----- 11----- 15----- 4--:-- 8--:-- 12--:-- 16--:-- 4----- 8----- 12-----...
DVD GEBRUIK DVD functies gebruiksinstructies 1. Afspelen (voor DVD/Super VCD/VCD/CD/CD-G/HD-CD en Mp3/JPEG discs) - Voor DVD disc, druk op de knop vanuit het hoofd- of titelmenu; terwijl u de DVD afspeelt kunt u uw favoriete titel direkt afspelen met de titelkeuze door te drukken op de TITLEknop.
Seite 75
DVD GEBRUIK • Voor DVD discs (2 pagina’s), druk eenmalig op de D.DISP knop om de eerste pagina te tonen, zoals hieronder: Disc Type Hoofdstuk -/-(Huidig/Vol) Verstreken disc tijd Titel -/-(Huidig/Vol) Druk nogmaals op de D. DISP knop om de tweede pagina, zoals hieronder, weer te geven: Audio Taal Audio Type...
Seite 76
DVD GEBRUIK 11. Ondertiteling (voor DVD en Super VCD discs) - Druk eenmalig op SUBTITLE om de huidige ondertiteling weer te geven. - Druk er nogmaals op om tussen opeenvolgende verschillende ondertiteling modussen te wisselen. NOTITIE: Voor multi-talen ondertiteling DVD & Super VCD discs, druk op de SUBTITLE knop om uw favoriete ondertitelingstaal te kiezen. 12.
DVD GEBRUIK - M.b.v. de navigatie knoppen kunt u uw favoriete map bekijken en het eerste bestand afspelen of verder gaan naar uw favoriete bestand. NOTITIE: - Druk op de knoppen om de markering van de mappen, dokumenten of modus selectie te bewegen. - Druk op de numerieke knoppen om de inhoud direkt te selecteren.
DVD GEBRUIK Systeem Setup SYSTEEM SET-UP NOTITIE: PAL formaat wordt meestal gebruikt voor TV's. WACHTWOORD Controleer uw TV gebruikshandleiding voor de ondersteunde formaten. Als LEEFTIJD NTSC geselecteerd is met een niet-compatibele TV kan het zijn dat u SET-UP VERLA. storing of beeldverschuivingen krijgt. TV Type DVD’s worden geproduceerd in verschillende scherm aspect ratio’s.
Seite 79
DVD GEBRUIK Wachtwoord - De standaard instelling is geblokkeerd. Geen bepalingskeuze of wijziging van het paswoord mogelijk. Om de bepalingsinstellingen te wijzigen, moet u het standaard paswoord “0000” met de numerieke toetsen invoeren en dan op ENTER drukken om te bevestigen. - Om het paswoord te wijzigen, voert u 4 willekeurige getallen is als de blokkade opgeheven is.
DVD GEBRUIK Taal Instellingen Druk op de DVD SETUP knop om het OSD menu in de DVD speler te activeren. INST. TAAL - OSD Taal Gebruik de navigatie knoppen om het OSD TAAL TAAL NEDERLANDS instellingen icoon te selecteren, druk op ENTER om te bevestigen.
DVD GEBRUIK MENU Taal INST. TAAL TAAL NEDERLANDS - Gebruik de navigatie knoppen om het MENU TAAL instellingen icoon te selecteren, druk op ENTER om te ONDERTITELING bevestigen. Er zijn 7 talen waar u uit kunt kiezen, druk op TAAL MENU &...
Seite 82
DVD GEBRUIK Dolby Digital Instellingen Dynamisch Bereik DIGITALE SET-UP DYN. BEREIK - Als u de compressie modus wijzigt naar “Audio output”, pas dan de compressie ratio aan voor een ander effekt. Als VOL geselecteerd is, is de waarde SET-UP VERLA. van het piek-signaal het kleinst.
PROBLEMEN OPLOSSEN Gelieve bij problemen eerst in deze lijst te kijken naar oorzaken van problemen en de bijbehorende oplossingen voordat u contact opneemt met het service personeel. DISPLAY PROBLEEM OPLOSSEN Symptoom Oorzaak en Oplossing • Zwart scherm, stroom Controleer of het netsnoer korrekt aangesloten is en of het indicator lampje uit apparaat aan is •...
CONSIGNES IMPORTANTES DE SÉCURITÉ Ce symbole indique la présence dans le boîtier de l’appareil de tensions dangereuses qui présentent des risques d’électrocution et de blessures corporelles. Ce symbole indique que d’importants conseils de fonctionnement sont fournis dans la documentation de ce produit. Veuillez lire attentivement ce manuel avant l’utilisation de ce produit.
Seite 91
CONSIGNES IMPORTANTES DE SÉCURITÉ • Ne pas placer la télé LCD/moniteur sur un chariot, un support, un trépied, une table ou un sol instables d’où elle risque de tomber. Si elle tombe elle sera endommagée, touchée ou rayée. Ne nettoyez pas le panneau frontal avec un produit de type acétone, de l'alcool éthylique, du toluène, de l'acide méthylique ou chlorhydrique car ils peuvent l'endommager.
Seite 92
SOMMAIRE PANNEAUX DES TOUCHES DE FONCTIONS Panneau frontal Clavier local EQUIPEMENT EXTERNE Schéma de branchement TÉLÉCOMMANDE Télécommande Touches de la télécommande (Mode TV) Touches de la télécommande (Mode DVD) Installation des piles DEMARRAGE Mise en marche Sélection de la source MANUAL DE L’OSD TELE Installation pour la première fois Informations télé...
PANNEAUX DES TOUCHES DE FONCTIONS PANNEAU FRONTAL Voyant (il est rouge en mode veille, vert en fonctionnement normal). Capteur infrarouge de la télécommande CLAVIER LOCAL (VERSIONS) TV+DVD (15,6“, 19“) TV+DVD (22“) TV/AV NEXT PLAY\ II PREV EJECT TV/AV STOP VOL+ PLAY\ II VOL- EJECT...
TÉLÉCOMMANDE TOUCHES DE LA TÉLÉCOMMANDE Mode TV 1. AUTO Réservé 2. MUTE Pour couper le son. 3. TOUCHES NUMERIQUES Pour sélectionner un numéro de chaîne (RAPPEL) Bascule entre la chaîne précédente et actuelle. 5. NICAM Affiche des informations concernant le son de la chaîne, sélectionne le son NICAM du canal. 6.
Seite 97
TÉLÉCOMMANDE TOUCHES DE LA TÉLÉCOMMANDE 23. STANDBY Bascule entre le mode veille et le mode allumé. 24. -/- - Bascule entre le mode un et deux chiffres d’entrée de numéro de canal. 25. ASPECT Change le rapport d’image selon la séquence : plein écran, Zoom1, Zoom2, Auto, 4:3, 14:9, 16:9, sous-titre 26.
Seite 99
TÉLÉCOMMANDE TOUCHES DE LA TÉLÉCOMMANDE Mode DVD (EJECT) Pour entrer/sortir un disque. 42. DVD SETUP Pour afficher le menu DVD. de configuration (LECTURE / PAUSE) Pour lancer ou suspendre la lecture. (STOP) Pour arrêter la lecture. (RALENTI) Différentes vitesses de lecture en séquence. (PRÉCÉDENT) Lecture jusqu’au Titre / Chapitre / Piste précédent.
TÉLÉCOMMANDE INSTALLATION DES PILES Retirez le couvercle des piles. Insérez deux piles SUM-4 (AAA) en faisant correspondre les polarités +/- des piles avec celles inscrites au fond du compartiment pour piles comme illustré : AUTONOMIE DES PILES • Normalement les piles peuvent durer un an. •...
DEMARRAGE Une fois l’appareil est placé sur une table / accroché au mur convenablement, et que tous les câbles, y compris l’alimentation, ont été branchés, tout ce qui vous reste à faire est : • D’appuyer sur la touche [STANDBY] (veille) de la télécommande pour mettre en marche la télé, le voyant devient vert.
MANUEL DE L’OSD Installation pour la première fois Installation Première Fois Pays Langue Francais Si c'est la première fois que vous allumez la télé, il n’y a Supprimer la fonction analogue Recherche d’un programme analog aucune chaîne mémorisée, le menu Installation Première Fois apparaît à...
Seite 104
MANUEL DE L’OSD Informations télé Informations sur la chaîne Appuyez sur la touche DISPLAY ou NICAM pour afficher les informations sur la chaîne. Pas de signal 1. Numéro de la chaîne courante. 2. Le système de couleurs de la chaîne courante, peut être réglé dans le menu Recherche Manuelle (une option du menu PARAMÉTRES).
MANUEL DE L’OSD Options du menu Vidéo Appuyez sur la touche MENU du panneau frontal ou la touche LCD-MENU de la télécommande pour ouvrir le menu principal. 1. Utilisez les touches pour sélectionner IMAGE dans le menu principal. IMAGE 2. Utilisez les touches pour sélectionner l’option Mode image que vous souhaitez régler dans le menu IMAGE.
MANUEL DE L’OSD Options du menu Audio Appuyez sur la touche MENU du panneau frontal ou la touche LCD-MENU de la télécommande pour ouvrir le menu principal. 1. Utilisez les touches pour sélectionner AUDIO dans le AUDIO menu principal. 2. Utilisez les touches pour sélectionner l’option que vous Mode Audio Personnel...
Seite 107
MANUEL DE L’OSD 1. Utilisez les touches pour sélectionner PARAMÉTRES dans le menu principal. 2. Utilisez les touches pour sélectionner l’option que vous souhaitez régler dans le menu PARAMÉTRES. 3. Utilisez les touches pour régler. 4. Lorsque vous êtes satisfait du réglage, appuyez sur la touche LCD-MENU pour retourner au menu précédent ou appuyez sur la touche EXIT pour quitter le menu principal.
Seite 108
MANUEL DE L’OSD Système Couleur Utilisez les touches pour sélectionner le système de couleurs correspondant tel que Auto, PAL, SECAM. Nom de la Chaîne Cette option vous permet de nommer une chaîne, vous pouvez aussi renommer des chaînes déjà nommées. 1.
MANUEL DE L’OSD Entrée VGA Menu Configuration de l’entrée VGA (pour régler la position de l’image PC) : Auto Horloge Position H Position V Placer Remise Selectionner Entrée HDMI Menu Configuration de l’entrée HDMI (pour régler la position de l’image HDMI) : Position H Position V Placer Remise...
MANUEL DE L’OSD Options du menu Minuterie Appuyez sur la touche MENU du panneau frontal ou la touche LCD-MENU de la télécommande pour ouvrir le menu principal. 1. Utilisez les touches pour sélectionner MINUTERIE dans le menu principal. MINUTERIE 2. Utilisez les touches pour sélectionner l’option que vous Minuterie Veille souhaitez régler dans le menu MINUTERIE.
Seite 111
MANUEL DE L’OSD Ecran bleu Cette option vous permet d'activer ou de désactiver le fond bleu de l’écran. Si cette option est activée, le fond de l’écran devient bleu en cas de signal faible ou absent. Enfant Cle A ppuyez sur la touche ENTER ou pour régler Enflan Cle.
Seite 112
MANUEL DE L’OSD Nouveau code Utilisez les touches numériques 0~9 pour entrer le nouveau code PIN. Changer le code Utilisez les touches numériques 0~9 pour rentrer le code PIN que vous avez entré dans le menu Nouveau Code PIN pour le confirmer. Cadenas hôtel Appuyez sur la touche pour ouvrir le menu Verrouillage hôtel.
Seite 113
MANUEL DE L’OSD Source initiale Utilisez les touches pour sélectionner la source par défaut parmi TV, Péritel, CVBS, S-VIDEO, VGA, HDMI ou DVD. Programme initial Utilisez les touches pour sélectionner la source par défaut dans le mode Hôtel. Volume max. Utilisez les touches pour sélectionner le volume maximum dans le mode Hôtel.
FONCTION TELETEXTE FONCTION TELETEXTE La plus part des stations de diffusion télévisé fournissent des informations télétexte gratuitement concernant la météo, les programmes télé, la bourse etc. Vous pouvez juste entrer le numéro de la page télétexte en fonction du contenu. MODES D’AFFICHAGE DU TELETEXTE •...
UTILISATION DU DVD Utilisation de base 1. Allumer et éteindre le DVD Allumez la télé LCD puis appuyez sur la touche INPUT de la télécommande. Utilisez les touches pour sélectionner le mode DVD et confirmez avec la touche ENTER. 2. Insérez un disque dans le DVD Insérez le disque dans la fente pour disque (la face imprimée doit être orientée vers la face de l’appareil), le lecteur chargera automatiquement le disque.
Seite 117
Utilisation du DVD Disques DVD/MP3/JPEG Disques Super VCD/ VCD/ CD /CD-G/ HD-CD --:-- 5--:-- 9--:-- 13--:-- ----- 5----- 9----- 13----- 2--:-- 6--:-- 10--:-- 14--:-- 2----- 6----- 10----- 14----- 3--:-- 7--:-- 11--:-- 15--:-- 3----- 7----- 11----- 15----- 4--:-- 8--:-- 12--:-- 16--:-- 4----- 8----- 12-----...
Seite 118
UTILISATION DU DVD Guide sur les fonctions DVD 1. Lecture (pour les disques DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD et MP3/ JPEG) Pour les disques DVD, appuyez sur à partir du menu principal ou du menu titre, en mode lecture, vous pouvez également lire directement un titre de votre choix en utilisant la touche TITRE.
Seite 119
UTILISATION DU DVD • Pour les disques DVD, (2 pages), appuyez sur D.DISP une première fois pour afficher la première page comme illustré ci-dessous : Type de disque Chapitre -/- (Courant/TOTAL) Temps écoulé dans le disque Titre -/- (Courant/TOTAL) Appuyez sur D.DISP une seconde fois pour afficher la seconde page comme illustré ci-dessous : Audio Langue Type Audio...
UTILISATION DU DVD 11. Sous-titrage (pour les disques DVD et Super VCD) Appuyez sur SUBTITLE une fois pour afficher le sous-titrage actuel. Appuyez de nouveau pour basculer entre les différents modes de sous-titrage. REMARQUE : Pour les disques DVD et Super VCD Multi-langues, appuyez sur SUBTITLE pour choisir votre sous-titrage favori. 12.
UTILISATION DU DVD - Au moyen des touches de navigation vous pouvez parcourir le contenu pour rechercher votre fichier ou répertoire favori. REMARQUE : - Utilisez les touches pour surligner des répertoires et des fichiers en vue de les sélectionner. - Utilisez les touches numériques pour sélectionner les éléments à...
UTILISATION DU Configuration Système CONFIG. SYST. SYSTEME TV REMARQUE : Le format PAL est utilisé généralement pour FORMAT AFFICH les télés. Consultez votre guide d'utilisateur CODE PIN pour les formats pris en charge par votre télé. Si vous choisissez NTSC avec une télé CONTR PARENT.
Seite 123
UTILISATION DU DVD Code PIN - Par défaut il est verrouillé. Aucune classification ou modification de mot de passe n'est possible. Pour éditer la classification, entrez le mot de passe par défaut “0000” au moyen des touches numériques, puis appuyez sur ENTER pour confirmer. Pour modifier le mot de passe, entrez 4 chiffres lorsque le verrouillage est levé.
Seite 124
UTILISATION DU DVD Choix de la langue Appuyer sur DVD SETUP pour ouvrir le menu écran du DVD. CONFIG. LANGUE - Langue de l'affichage écran (OSD) LANGUE OSD FRANCAIS Utilisez les touches de navigation pour la sélection le l'icône LANGUE AUDIO de configuration de la langue de l'affichage écran, appuyez sur ENTER pour confirmer.
UTILISATION DU DVD Langues des Menu CONFIG. LANGUE LANGUE OSD FRANCAIS - Utilisez les touches de navigation pour la sélection LANGUE AUDIO le l'icône LANGUE MENU, appuyez sur ENTER LANG SS-TITRES pour confirmer. Il y a 7 langues à votre choix, utilisez les touches pour basculer entre les LANGUE MENU...
UTILISATION DU DVD Configuration Dolby Digital Gamme dynamique CONFIG. NUMER DYNAMIQUE - Ajustez les différents taux de compression lorsque vous passez en mode “Audio output” (sortie Audio). Si vous sélectionnez MAX, la valeur du pic de signal est QUITTER MENU la plus petite.
DÉPANNAGE Avant de contacter un service de réparation, consultez le tableau suivant pour essayer de résoudre le problème par vous-même. PROBLEMES D’AFFICHAGE Symptôme Causes et remède • Vérifiez si la prise d’alimentation est bien branchée et si Écran noir, voyant alimentation éteint l’appareil est allumé...
Seite 128
SPÉCIFICATIONS 15,6" : 40 cm / 19" : 48 cm / 22" : 56 cm Taille Ecran LCD Type TFT couleur Système vidéo PAL, SECAM Système audio BG, DK, I, L/L’ Canaux reçus 200 CH Entrée vidéo Format Jusqu’à 1680 x1050 @60Hz PC-RGB Fréquence H 30~80 KHz...
WICHTIGE SICHERHEITSHINWEISE Der Blitz im gleichseitigen Dreieck weist auf gefährliche Hochspannung im Gerät hin, die zu Stromschlag führen kann. Das Ausrufungszeichen im gleichseitigen Dreieck weist auf wichtige Bedienungs- und Wartungsanleitungen hin. Bitte lesen Sie die Bedienungsanleitung vor Gebrauch aufmerksam durch. •...
Seite 135
WICHTIGE SICHERHEITSHINWEISE • Fernseher nicht auf unstabilen Wagen, Stand oder Tisch stellen. Er kann herunterfallen und erhebliche Beschädigung des Geräts verursachen. Bildschirm nicht mit Lösungsmitteln in Berührung bringen, das führt zu Schäden. • Stellen Sie das Netzteil in Steckdosennähe auf. •...
Seite 136
INHALT TASTENBELEGUNG UND FUNKTIONEN Frontblende Tastenbelegung ANSCHLÜSSE Anschlussdiagramm FERNBEDIENUNG Tastenbelegun Fernbedienung Tastenbelegung (DVD Modus) Batterien einsetzen ERSTE SCHRITTE Einschalten Auswahl der Eingangsquelle ATV BILDSCHIRMMENÜ Erst-Installation TV Informationen Video Menü Audio Menü Setup Menü VGA / HDMI Eingang Uhrzeit Menü 18 Funktionen Menü VIDEOTEXT Videotext Allgemeine Bedienugnshinweise...
TASTENBELEGUNG UND FUNKTIONEN FRONTBLENDE IR Sensor TASTENBELEGUNG TV+DVD (22“) TV/AV NEXT PREV STOP VOL+ PLAY\ II VOL- EJECT MENU POWER TV/AV Auswahl der Eingangsquelle CH+ Kanalwahl aufwärts CH- Kanalwahl abwärts VOL+ Lautstärke erhöhen VOL- Lautstärke verringern MENU Menü aufrufen oder verlassen POWER ein- und ausschalten (Stand-by) NEXT –...
FERNBEDIENUNG TASTENBELEGUNG TV+DTV Modus 1. AUTO Nicht belegt. 2. MUTE Stummschaltung. 3. Zifferntasten Eingabe der Kanalnummer. (ZURÜCK) Umschalten zwischen dem aktuellen und vorherigen Kanal . 5. NICAM Anzeige von Ton-Informationen. 6. CH+ Kanalwahl aufwärts. 7. DISPLAY Anzeige des Wiedergabestatus. 8. CH- Kanalwahl abwärts .
Seite 141
FERNBEDIENUNG TASTENBELEGUNG 23. STANDBY Ein- und ausschalten (Stand-by) des Geräts. 24. -/-- Eingabe von mehrstelligen Kanalnummern. 25. ASPECT Durchlaufen der Einstellungen des Bildseitenverhältnisses: Vollbild, Zoom1, Zoom2, Auto, 4:3, 14:9, 16:9, Untertitel. 26. VOL+ Lautstärke erhöhen. 27. VOL- Lautstärke verringern. (LINKS) Navigation links im Menü...
Seite 143
FERNBEDIENUNG TASTENBELEGUNG DVD Modus (EJECT) Einziehen und ausgeben einer Disc. 42.DVD SETUP Anzeige des DVD Einstellungsmenüs. (WIEDERGABE/PAUSE) Wiedergabe oder Unterbrechung der Wiedergabe. (STOPP) Wiedergabe beenden. (ZEITLUPE) Aufrufen der Zeitlupengeschwindigkeiten. (ZURÜCK) Zurück zum vorherigen Titel / Kapitel / Track. (WEITER) Weiter zum nächsten Titel / Kapitel / Track. 48.
FERNBEDIENUNG BATTERIEN EINSETZEN Öffnen Sie das Batteriefach. Setzen Sie zwei R03 (AAA) Batterien mit korrekter Polarität ein, wie innen im Batteriefach aufgedruckt: BATTERIE LEBENSDAUER • Lässt die Reichweite der Fernbedienung nach, so sind die Batterien erschöpft und müssen ausgetauscht werden. HINWEISE •...
ERSTE SCHRITTE Nachdem das Gerät ist richtig plaziert auf den Tisch oder die Wand und alle henötigten Kahel und Strom angeschlossen hahen, ist der nächste dann sollten Sie sich: Drücken Sie die [STANDBY] Taste auf der fernbedienung, um das Gerät einschalten. Sie werden sehen die grüne LED - Anzeige.
BILDSCHIRMMENÜ Erstinstallation Ersinstallation Land Sprache Deutsch Bei Erstanschluss Ihres neuen Fernsehers ist kein Kanal Analogprogramm l schen ö gespeichert und das First Time Installation Menü wird Analogprogramm suchen angezeigt. Auswahl Einstellen Land wählen Sie Ihr Land. Sprache wählen Sie Ihre Bildschirmsprache. Analogprogramm löschen wählen Sie, ob Sie alle gespeicherten Analogkanäle löschen wollen.
BILDSCHIRMMENÜ TV Informationen Programm-Informationen Drücken Sie DISPLAY oder NICAM zur Anzeige der Programm-Informationen. 1. Aktuelle Kanalnummer. 2. Farbsystem des aktuellen Kanals, kann im Menü Programmsuchlauf gewählt werden (Option im SETUP Menü). 3. Die Bezeichnung des aktuellen Kanals. 4. Die Bezeichnung des aktuellen Kanals, kann im Menü Programmsuchlauf gewählt werden (Option im SETUP Menü).
BILDSCHIRMMENÜ VIDEO Menü Drücken Sie MENU auf dem Gerät oder LCD-MENU auf der Fernbedienung zum Aufrufen des Hauptmenüs. 1. Mit wählen Sie im Hauptmenü BILD. BILD 2. Mit wählen Sie die einzustellende Option im Bildmodus BILD Menü. 3. Mit nehmen Sie die Einstellung vor. Helligkeit 4.
BILDSCHIRMMENÜ AUDIO Menü Drücken Sie MENU auf dem Gerät oder LCD-MENU auf der Fernbedienung zum Aufrufen des Hauptmenüs. 1. Mit wählen Sie im Hauptmenü TON. 2. Mit wählen Sie die einzustellende Option im TON Volumen Menü. Ton-Modus Persönlich 3. Mit nehmen Sie die Einstellung vor.
Seite 151
BILDSCHIRMMENÜ 1. Mit wählen Sie im Hauptmenü SET-UP. 2. Mit wählen Sie die einzustellende Option im SET-UP Menü. 3. Mit nehmen Sie die Einstellung vor. 4. Nach erfolgter Einstellung drücken Sie erneut LCD-MENU zur Rückkehr in das vorherige Menü oder drücken Sie EXIT zum Verlassen des Hauptmenüs.
Seite 152
BILDSCHIRMMENÜ Farb System wählen Sie das entsprechende Farb System: Auto, PAL oder SECAM. Programmname Hier können Sie die Kanäle benennen oder umbenennen. 1. Wählen Sie einen zu benennenden Kanal. 2. Mit wählen Sie im SET-UP Menü Programmname. 3. Mit wählen Sie aus, das Kanalbenennungsmenü wird angezeigt: Programmname 4.
BILDSCHIRMMENÜ UHRZEIT Menü Drücken Sie MENU auf dem Gerät oder LCD-MENU auf der Fernbedienung zum Aufrufen des Hauptmenüs. 1. Mit wählen Sie im Hauptmenü UHRZEIT. UHRZEIT 2. Mit wählen Sie die einzustellende Option im UHRZEIT Schlafmodus - Timer Menü. 3. Mit nehmen Sie die Einstellung vor.
Seite 155
BILDSCHIRMMENÜ Blauer Bildschirm Hier aktivieren/deaktivieren Sie den blauen Hintergrund. Falls aktiviert, erscheint der Bildschirm blau, wenn das Eingangssignal zu schwach ist. Kindersicherung Mit ENTER oder stellen Sie die Kindersicherung ein. Ist die Kindersicherung aktiviert, so benötigen Sie Ihren PIN-Code. Mit ENTER geben Sie Ihren PIN-Code ein. Löschen Bestätigen TIPP: Das Administrator-Passwort ist 4711.
Seite 156
BILDSCHIRMMENÜ Neue Geheimzahl Mit den Zifferntasten 0~9 geben Sie den neuen PIN-Code ein. Erneute Eingabe Mit den Zifferntasten 0~9 geben Sie den PIN-Code erneut zur Bestätigung ein, den Sie unter Neuer PIN-Code eingegeben haben. Hotel - Sperre Drücken Sie die Taste, um das Hotel - Sperre Menü...
Seite 157
BILDSCHIRMMENÜ Vorgegebene Quelle Drücken Sie , um die Quelle zu wahlen, aus TV, SCART, CVBS, S-VIDEO, VGA, HDMI, DTV. Vorgegebene Prog. Drücken Sie , um die vorgegebene Programm im Hotel-Modus. Max. Lautstarke Drücken Sie , um die maximale Lautstärke zu abstimmen im Hotel-Modus. Entsperren Drucken Sie , um die Sperre Einstellungen zu freischalten im Hotel-Modus.
VIDEOTEXT VIDEOTEXT Die meisten Fernsehsender liefern kostenfreie Videotext-Informationen, einschließlich der neuesten Nachrichten, Wettervorhersage, TV-Programmübersicht und Börseninformationen. Geben Sie die Videotextseite entsprechend der Indexseite ein. • VIDEOTEXT MODI • Wählen Sie einen Kanal mit Videotextsignal. • Mit [TEXT] aktivieren Sie den Videotextmodus. •...
DVD-BETRIEB Allgemeine Bedienungshinweise 1. Ein- und ausschalten der DVD Funktion - Schalten Sie den LCD TV ein und drücken Sie INPUT auf der Fernbedienung. Mit wählen Sie den DVD Modus und bestätigen mit ENTER. 2. Disc einlegen - Führen Sie die Disc in den Laufwerkschlitz ein (Aufdruck nach vorn), der Player lädt die Disc automatisch. Im Display wird erst „SCHLIESSEN”...
DVD-BETRIEB DVD Funktionen 1. Wiedergabe (DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD und MP3/ JPEG Discs) - Für DVD’s, mit Tastendruck im Stamm- oder Titelmenü, während der DVD Wiedergabe Direktauswahl mit TITLE. - Für Super VCD’s und VCD Discs im Wiedergabemodus Direktauswahl mit den Zifferntasten. (HINWEIS: In Programmwiedergabe oder mit aktivierter PCB Funktion Wechsel des Soundtracks nur mit oder - For CD, CD-G und HD-CD Discs im Wiedergabemodus Direktauswahl mit den Zifferntasten.
Seite 163
DVD-BETRIEB • Für DVD’s (2 Seiten) drücken Sie einmal D.DISP zur Anzeige der ersten Seite: Disc Typ Kapitel -/-(aktuell/gesamt) Vergangene Spielzeit Disc Titel -/-(aktuell/gesamt) Mit erneutem Tastendruck auf D. DISP zeigen Sie die zweite Seite an: Audio Sprache Audio Typ Blickwinkel EIN/AUS -/-(aktuell/gesamt) oder AUS Untertitel -/-(aktuell/gesamt) oder AUS...
DVD-BETRIEB 11. Untertitel (DVD und Super VCD Discs) - Mit einfachem Tastendruck auf SUBTITLE zeigen Sie die aktuelle Untertitelsprache an. - Mit erneutem Tastendruck durchlaufen Sie die Untertitelsprachen. HINWEIS: Für mehrsprachig untertitelte DVD’s und Super VCD’s drücken Sie SUBTITLE zur Auswahl Ihrer gewünschten Untertitelsprache. 12.
DVD-BETRIEB - Mit den Navigationstasten haken Sie die gewünschte Datei ab, die Wiedergabe der ersten Datei beginnt. HINWEIS: - Mit markieren Sie Datei oder Modus. - Mit den Zifferntasten rufen Sie eine Datei direkt auf. Für Tracknummern größer als 10 drücken Sie zunächst 0 (z.B. für Tracknummer 15 erst 0 und dann 5 drücken).
DVD-BETRIEB Systemeinstellungen - EINST. HINWEIS: PAL ist die Standardeinstellung. Lesen Sie Einzelheiten in der Bedienungsanleitung Ihres Fernsehers KIND - SICHER nach. Ist NTSC gewählt, so kann es zu STANDARD Bildstörungen kommen. EINST. VERL. TV Typ DVD’s werden in einer Vielzahl von Bildseitenverhältnissen hergestellt. Hier wählen Sie aus: - EINST.
Seite 167
DVD-BETRIEB Passwort - Die Standardeinstellung ist gesperrt. Es kann keine Bewertung gewählt, das Passwort kann nicht geändert werden. Zur Umstellung der Bewertung geben Sie das werkseitige Passwort 0000 mit den Zifferntasten ein, dann bestätigen Sie mit ENTER. - Zur Änderung des Passwortes geben Sie eine vierstellige Zahl ein. - EINST.
DVD-BETRIEB Sprachen-Einstellung DVD SETUP rufen Sie das Einstellungsmenü auf. SPRACHE EINST. - OSD Sprache SPRACHE DEUTSCH Mit den Navigationstasten wählen Sie OSD SPRACHE, mit ENTER - SPRACHE bestätigen Sie. Ihnen stehen 7 Sprachen zur Verfügung, die Sie mit UNTERTIT. SPR. ü...
DVD-BETRIEB Menüsprache SPRACHE EINST. SPRACHE DEUTSCH - SPRACHE - Mit den Navigationstasten wählen Sie MENÜSPRACHE, mit ENTER UNTERTIT. SPR. ü SPRACHE bestätigen Sie. Ihnen stehen 7 Sprachen zur Verfügung, die Sie mit durchlaufen. Mit ENTER bestätigen Sie. EINST. VERL. Audio-Einstellungen Audio Verl.
DVD-BETRIEB Dolby Digital Einstellungen Dynamik - EINST - Einstellung der Kompressionsrate für Soundeffekte. Bei Auswahl von VOLL ist das Spitzensignal gering, bei Auswahl von AUS ist das Signal EINST. VERL. hoch. - EINST. - Umschalten zwischen vier Ausgangsmodi, STEREO, MONO L, MONO R, EINST.
STÖRUNGSERKENNUNG Bevor Sie sich mit einem Problem an den Kundendienst wenden, versuchen Sie bitte zunächst eine Problemlösung anhand nachstehender Liste: DISPLAY Problem Mögliche Ursache und Lösungsvorschlag • Kein Bild, Status LED Überprüfen Sie, ob der Netzstecker in der Steckdose ist und leuchtet nicht.
