QUICK REFERENCE GUIDE About This Guide The Ovation F-415FC Quick Reference Guide (QRG) has basic product information such as connection, mounting, menu options, and DMX values. Download the User Manual from www.chauvetprofessional.com for more details. Disclaimer The information and specifications contained in this QRG are subject to change without notice.
This product has an auto-ranging power supply that can work with an input voltage range of 100–240 VAC, 50/60 Hz. Power Linking It is possible to link up to 13 Ovation F-415FC products at 120 VAC, 22 products at 208 V, or 24 products at 230 VAC. Never exceed this number. Power-linking cords can be purchased separately.
Seite 4
Virtual Color Wheel (VCW) The Ovation F-415FC includes a feature called the Virtual Color Wheel (VCW). This feature is available as a standalone control mode for manual use and as a control channel in select DMX personalities. More than 30 premixed colors, custom blended by Chauvet engineers, are available to call up for easier programming.
Seite 5
14-channel: dimmer, RGBAL, strobe, virtual color 14Ch wheel, color temperature, auto show, auto speed, control, zoom, motor reset 18-channel: 16-bit RGBAL and dimmer, strobe, 18Ch virtual color wheel, color temperature, zoom, motor reset, control 3-channel: hue, saturation, value Ovation F-415FC QRG Rev. 7...
Seite 6
Selects automatic programs and auto program speed Zoom 0–255 Controls zoom Red Shift Mimics halogen lamp dimming Master Receives DMX signal from the DMX controller (master) Master/ Slave Slave Receives DMX signal from the master unit Ovation F-415FC QRG Rev. 7...
Seite 7
Use proper protective equipment to prevent burns. Keep a safe distance from flammable objects. NOTICE: When operating in Fan Mode: Off, output of the fixture will be reduced and will not reach the same levels as when using other fan modes. Ovation F-415FC QRG Rev. 7...
Seite 8
Dimmer speed mode 2 088 095 Dimmer speed mode 3 096 103 Fan auto 104 111 Fan on 112 119 Fan off 120 127 Fan silent 128 255 No function (reserved) Ovation F-415FC QRG Rev. 7...
Seite 9
120 127 Fan silent 128 255 No function (reserved) Zoom 000 255 Narrow to wide 000 200 No function Motor reset 201 220 Motor reset 221 255 No function Ovation F-415FC QRG Rev. 7...
Seite 10
000 255 0–100% Green 000 255 0–100% Blue 000 255 0–100% Amber 000 255 0–100% Lime 000 255 0–100% 000 010 No function Strobe 011 255 Strobe, slow to fast Ovation F-415FC QRG Rev. 7...
Seite 11
Refer to Color Temperature Chart Channel Function Value Percent/Setting Dimmer 000 255 0–100% (color set through menu) Channel Function Value Percent/Setting 000 255 0–100% Saturation 000 255 0–100% Value 000 255 0–100% Ovation F-415FC QRG Rev. 7...
GUÍA DE REFERENCIA RÁPIDA Acerca de Esta Guía La Guía de Referencia Rápida (GRR) del Ovation F-415FC contiene información básica sobre el producto, como montaje, opciones de menú y valores DMX. Descargue el Manual de Usuario de www.chauvetprofessional.com para información más detallada.
240 VCA, 50/60 Hz. Alimentación en Cadena Puede enlazar hasta 13 productos Ovation F-415FC a 120 V, 22 productos a 208 V o 24 productos a 230 V. Nunca sobrepase este número. Los cables de alimentación en cadena se pueden adquirir por separado.
Seite 14
Rueda de Color Virtual (VCW) El Ovation F-415FC incluye una función de rueda de color virtual llamada Virtual Color Wheel (VCW). Esta función está disponible como modo de control independiente para uso manual y también como canal de control en algunas personalidades DMX del dispositivo.
VCW, temperatura de color, programas 14Ch automática, velocidad automática, control, zoom, reinicio del motor 18 canales: atenuador, fino atenuador, 16-bit 18Ch control RVAAL, estroboscopio, VCW, temperatura de color, zoom, reinicio del motor, control 3 canales: tono, saturación, valor Ovation F-415FC QRG Rev. 7...
Seite 16
Auto Show Auto 1–5 1–100 programas automáticos Zoom 0–255 Controla el zoom Red Shift Imita la atenuación de una lámpara halógena Master Recibe señales DMX del controlador DMX (maestro) Master/ Slave Slave Recibe señales del maestro Ovation F-415FC QRG Rev. 7...
Seite 17
Utilice un equipo de protección adecuado para evitar quemaduras. Mantenga una distancia de seguridad con objectos inflamable. AVISO: Cuando funcione en modo ventilador: apagado, bajará el rendimiento del aparato y no alcanzará los mismos niveles que cuando use otros modos de ventilador. Ovation F-415FC QRG Rev. 7...
Seite 18
Establece el ventilador a modo auto 104 111 Establece el ventilador a modo siempre encendido 112 119 Establece el ventilador siempre apagado 120 127 Establece el ventilador en silencio 128 255 Sin función (reservado) Ovation F-415FC QRG Rev. 7...
Seite 19
Establece el ventilador en silencio 128 255 Sin función (reservado) Zoom 000 255 Estrecho a ancho 000 200 Sin funciòn Reinicio del motor 201 220 Reinicio del motor 221 255 Sin funciòn Ovation F-415FC QRG Rev. 7...
Seite 20
000 255 0–100% Verde 000 255 0–100% Azul 000 255 0–100% Ámbar 000 255 0–100% Lima 000 255 0–100% 000 010 Sin función Estroboscopio 011 255 Estroboscopico, lento a rápido Ovation F-415FC QRG Rev. 7...
Seite 21
Referirse a Gráfico de temperaturas de color Canal Función Valor Porcentaje/Configuración Atenuador 000 255 0–100% Canal Función Valor Porcentaje/Configuración Tono 000 255 0–100% Saturación 000 255 0–100% Valor 000 255 0–100% Ovation F-415FC QRG Rev. 7...
MANUEL DE RÉFÉRENCE À Propos de ce Manuel Le Manuel de Référence du Ovation F-415FC (MR) reprend des informations de base sur cet appareil notamment en matière de connexions, montage, options de menu et valeurs DMX. Télécharger le Manuel d'Utilisation sur www.chauvetprofessional.com...
VCA, 50/60 Hz. Connexion Électrique Vous pouvez connecter jusqu’à 13 Ovation F-415FC à 120 V, 22 unités à 208 V ou 24 unités à 230 V. Ne dépassez jamais cette limite. Vous pouvez vous procurer séparément des cordons d'alimentation. Prise CA Connexion Câble (États-Unis)
Seite 24
Roue de Couleurs Virtuelles (VCW) Le Ovation F-415FC dispose d'une fonction appelée Roue de Couleur Virtuelle (VCW - Virtual Color Wheel). Cette fonction est disponible en mode de contrôle autonome pour une utilisation manuelle mais également en tant que canal de contrôle dans certaines personnalités DMX.
Seite 25
VCW, température de couleur, 14Ch programmes automatique, vitesse automatique, control, zoom, réinitialisation du moteur 18 canaux: gradateur 16-bit, RVBAL control 16-bit, 18Ch stroboscope, VCW, température de la couleur, zoom, réinitialisation du moteur, control 3 canaux: hue, saturation, value Ovation F-415FC QRG Rev. 7...
Seite 26
1–100 vitesse auto Zoom 0–255 Commande du zoom Red Shift Imite la gradation des lampes halogènes Recevez le signal DMX du contrôleur DMX Master Master/ (maître) Slave Slave Recevoir le signal de l'unité maître (esclave) Ovation F-415FC QRG Rev. 7...
Seite 27
REMARQUE: Lors du functionnement en mode ventilateur: Lorsque le ventilateur est à l’arret, le rendement de l’appareil est réduit et ne peut pas atteindre lesmêmes niveaux que lors de l’utilisation des autres modes de ventilateur. Ovation F-415FC QRG Rev. 7...
Seite 28
Mode vitesse du gradateur 3 096 103 Mode ventilateur automatique 104 111 Mode ventilateur activé 112 119 Mode ventilateur désactivé 120 127 Mode ventilateur silencieux 128 255 Pas de fonction (réservé) Ovation F-415FC QRG Rev. 7...
Seite 29
128 255 Pas de fonction (réservé) Zoom 000 255 Étroit à large 000 200 Pas de fonction Réinitialisation du moteur 201 220 Réinitialisation du moteur 221 255 Pas de fonction Ovation F-415FC QRG Rev. 7...
Seite 30
0–100% Vert 000 255 0–100% Bleu 000 255 0–100% Ambre 000 255 0–100% Lime 000 255 0–100% 000 010 Pas de fonction Stroboscope 011 255 Stroboscope, lent à rapide Ovation F-415FC QRG Rev. 7...
Seite 31
Consultez la section Gamme des températures de couleur Canal Fonction Valeur Pourcentage/Configuration Gradateur 000 255 0–100% Canal Fonction Valeur Pourcentage/Configuration Teint 000 255 0–100% Saturation 000 255 0–100% Valeur 000 255 0–100% Ovation F-415FC QRG Rev. 7...
SCHNELLANLEITUNG Über diese Schnellanleitung In der Schnellanleitung des Ovation F-415FC finden Sie die wesentlichen Produktinformationen, wie etwa über den Anschluss, die Montage, Menüoptionen und DMX-Werte des Geräts. Laden Sie für weiterführende Informationen unter www.chauvetprofessional.com das Benutzerhandbuch herunter. Haftungsausschluss Die in dieser Anleitung aufgeführten Informationen und Spezifikationen können ohne vorherige Ankündigung geändert werden.
Serienschaltung der Geräte Sie können bis zu 13 Ovation F-415FC Geräte bei 120 V AC, 22 Geräte bei 208 V und 24 Geräte bei 230 V AC in Serie schalten. Diese Anzahl niemals überschreiten! Stromkabel für die Serienschaltung können separat erworben werden.
Seite 34
SCHNELLANLEITUNG Virtuelles Farbrad (VCW) Der Ovation F-415FC verfügt über eine Funktion mit der Bezeichnung Virtuelles Farbrad ( Virtual Color Wheel, VCW). Diese Funktion steht als Stand-alone-Steuerungsmodus für die manuelle Bedienung sowie als Steuerungskanal bei ausgewählten DMX-Eigenschaften zur Verfügung. Es sind mehr als 30 von unseren Technikern vorgemischte Farben verfügbar, um die Programmierung einfacher zu gestalten.Die zum Mischen dieser Farben verwendeten DMX-Werte sind...
Seite 35
14 Kanal: Dimmer, RGBAL, Stroboskopeffekt, Channel Virtuelles Farbrad, Farbtemperatur, Auto-programm, 14Ch Auto-Geschwindigkeit, Steurung, Zoom, Motor zurücksetzen, Rotverschiebung 18 Kanal: 16-bit RGBAL und Dimmer, Stroboskopeffekt, Virtuelles Farbrad, 18Ch Farbtemperatur, Zoom, Motor zurücksetzen, Rotverschiebung, Steurung 3 Kanal: Farbton, Farbsättigung, Farbwert Ovation F-415FC SAL Rev. 7...
Seite 36
Auto Show Auto 1–5 1–100 Geschwindigkeit aus Zoom 0–255 Zur Steuerung des Zoom Red Shift Ahmt die Dimmung einer Halogenlampe nach Master Empfängt DMX-Signal vom DMX-Controller (Master) Master/ Slave Slave Empfängt das DMX-Signal vom Master-Gerät Ovation F-415FC SAL Rev. 7...
Seite 37
Verwendung anderer Lüftermodi. Verwenden Sie geeignete Schutzausrüstung, um Verbrennungen zu vermeiden. Halten Sie einen Sicherheitsabstand zu brennbaren Gegeständen ein. HINWEIS: Im Lüftermodus: Aus wird der Ausgang des Geräts reduziert und erreicht nicht die gleichen Pegel wie bei Verwendung anderer Lüftermodi. Ovation F-415FC SAL Rev. 7...
Seite 38
080 087 Dimmer-Geschwindigkeitsmodus 2 088 095 Dimmer-Geschwindigkeitsmodus 3 096 103 Fan-Auto 104 111 Lüfter an 112 119 Lüfter aus 120 127 Lüfter leise 128 255 Keine Funktion (reserviert) Ovation F-415FC SAL Rev. 7...
Seite 39
Lüfter aus 120 127 Lüfter leise 128 255 Keine Funktion (reserviert) Zoom 000 255 Eng bis weit 000 200 Keine Funktion Motor zurücksetzen 201 220 Motorzurücksetzung 221 255 Keine Funktion Ovation F-415FC SAL Rev. 7...
BEKNOPTE HANDLEIDING Over deze handleiding De Ovation F-415FC Beknopte Handleiding (BH) bevat basisinformatie over het product, zoals aansluiting, montage, menu- opties en DMX-waarden. Download de gebruikershandleiding op www.chauvetprofessional.com voor meer informatie. Disclaimer De informatie en specificaties in deze BH kunnen zonder voorafgaande kennisgeving worden gewijzigd.
Seite 43
Dit product heeft een voeding met automatisch bereik die werkt met een ingangsspanning van 100–240 VAC, 50/60 Hz. Power Linking U kunt tot 13 Ovation F-415FC-producten koppelen bij 120 V, 22 producten bij 230 V, 24 producten bij 230 V. Dit aantal niet overschrijden. Power Linking-snoeren kunnen apart aangeschaft worden.
Seite 44
BEKNOPTE HANDLEIDING Virtueel kleurenwiel De Ovation F-415FC ibevat een functie, genaamd het virtuele kleurenwiel (Virtual Color Wheel, VCW). Deze functie is beschikbaar als een losstaande bedieningsmodus voor handmatig gebruik en ook als een bedieningskanaal in de geselecteerde DMX-persoonlijkheden van de producten. Voor eenvoudiger programmering zijn er meer dan 30 voorgemengde kleuren beschikbaar die speciaal door onze technici zijn samengesteld.
Seite 46
Selecteert automatische programma’s en Auto Show Auto 1–5 1–100 automatische programmasnelheid Zoom 0–255 Controleert de zoom Red Shift Bootst halogeenlamp dimmen na Master Ontvangt DMX-signalen van de DMX-controller Master/ Slave Slave Ontvangt DMX-signalen van de master Ovation F-415FC QRG Rev. 7...
Seite 47
Gebruik de juiste beschermende uitrusting om brandwonden te voorkomen. Houd een veilige afstand van brandbare voorwerpen. LET OP: Bij werking in de ventilatormodus: Uit, uitvoer van de armatuur wordt verminderd en zal niet dezelfde niveaus bereiken als bij andere ventilatormodi. Ovation F-415FC QRG Rev. 7...
Seite 52
Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., U.K., Ireland, Benelux, France, Germany, or Mexico, contact the dealer of record. UL 1573 CSA C22.2 No. 166 E113093 Ovation F-415FC QRG Rev. 7...
