Thank you for purchasing the Logic3 LCD ProDock. As with all Logic3 products it has been built to the highest manufac-
turing standards and tested throughout its development, to ensure you get the best possible product. Please read through
and familiarize yourself with this manual before you use the LCD ProDock.

Product overview

ProDock LCD
Remote
Interchangeable Plugs
Control
(Euro 2pin and BS 3pin)
Pairing of lcD remote and ProDock
1
DC 5V 2A
4
3 secs
LED Flashing
Downloaded from www.Manualslib.com
AC Adapter with Batteries iPhone 3Gs A/V Cable
AAA x 2 Cradle
2 3
Loading...
5 6
Pairing Mode
1.Press & Hold
'Connect' button
for 3 secs (bottom
of the ProDock)
2.Press 'Select' to
continue
2
manuals search engine
6
Connection
Successful!
Component
Cable
connecting the lcD remote with the ProDock
1. Plug in the DC jack to the rear of the ProDock (DC 5V) Select and fit the correct plug adapter to suit your power supply.
Plug the power supply into your mains socket and turn the mains socket ON.
2. Press to switch ON the LCD remote control.
No Signal 3. Press and hold 'Select' button (Enables connecting mode on the remote control), if "No Signal" Message is displayed
Please turn ON the
on the screen.
ProDock
Press and Hold
'Select' to start the 4. Press and hold 'Connect' button (located on the bottom of the ProDock) until the blue LED flashes quickly on front of
connection
the dock (Enables connecting mode on the Pro Dock)
5. Press 'Select' button until LCD remote screen shows 'Connecting with ProDock'.
6. LCD will show 'Pairing in Progress'
7. Once pairing is established the LCD remote control screen will show 'Connection Successfully'.
8. Blue LED on the ProDock will now stop flashing and stay on constantly.
Note: Once your dock is already connected it is not necessary to perfom the connecting process again. To
4 secs
connect the ProDock to the LCD remote just connect power to the ProDock, dock your iPhone/ iPod on to the
ProDock and press any key on the LCD remote. (LCD remote control and ProDock will automatically connect)

lED status Indicator

- Solid – Remote and ProDock Conencted
- Flashing (Slowly): LCD Remote and ProDock Not Connected
Connecting with
ProDock.....
- Flashing (Quickly): ProDock in Connecting mode
6
