Olight OPEN 2 Handbuch

USER MANUAL
OPEN 2
Thank you for purchasing this Olight
Product. Please read this manual
carefully before use and keep it for
future reference!
IN THE BOX
OPEN 2
Refill
SPECIFICATIONS
20min
HIGH
120lumens
100%
40min
MEDIUM
60lumens 100%
2h
LOW
20lumens 100%
8h
MOON 100%
5lumens
(L)5.71* (D)0.5in
16m 64cd
(L)145 *(D)12.7mm
All above specifications are test results based on ANSI/NEMA FL1-2009 Standard.
PRODUCT OVERVIEW
The product is separable; the lower part is a pen, the upper part is a flashlight and a
central blue ring used as a separation point.
Pocket clip
Decorative Ring
L-Type Track
CHARGING
Unscrew the pen from the middle and store the lower part (pen). Connect the upper part to
the USB power supply or computer USB port via the provided charging cable (USB power
supply not included, users can use digital products or household appliance USB power
supply). The LED lights up red to indicate charging, and the red will go out when it is fully
charged.
USB Charging Cable
10%
NOTE:
80%
10min
* Before first use, please fully charge the product.
* Plugin the USB cable again when it is full charged, the charging indicator will still be Red
75%
20min
for about 30 seconds.
* The product uses a USB-C charging interface with 4.2V 200mA constant current and
70%
2h
voltage for charging. It can be fully charged in 55 minutes.
REFILL REPLACEMENT
a.Unscrew the tip, take out the refill and remove the spring from the refill.
1.34oz / 38g
Unscrew
1
b.Put the spring on the new refill, place the new refill back into the pen and tighten
the tip.
Install The Spring
Switch
LED Light
Tighten
Pen Push Button
Stainless Steel Tip
Unscrew
Red OFF:
Fully Charged
Remove The Spring
2
Insert The Refill
2
1
3
Red:
Charging
