4. Assembling the playpen
Step 1
Please unfold the playpen as shown on the picture on the previous page. Fold the sides up. Connect a
short and one long side by means of screws D and the cylindrical nuts C.
Step 3 : Changing the position of the base
Redo all actions of step 2 in reversed order. Replace the crochet hooks on a different level and repeat step
2.
Kinderpark met verstelbare bodem
Laufgitter mit verstelbarer Boden
info@basicbaby.be
Step 2 : Use the parts of step 2, the bottom (G), 4 crochet hooks (L), 4 spa-
cers (N), 4 bolts (K) and the 4 nuts M6 (M)
Place the crochet hooks in the provided openings on the wooden bars of the
long sides. Pay attention that the four of these are on the same height of one
of the possible positions for the base. Insert the base G into the playpen and
let it rest on the crochet hooks. Push a short bolt through an opening of the
base and the underlying crochet hook, place one spacer, a nut and thighten
slightly. Repeat for the remaining three bolts. Finally tighten all fi rmly.
17
By Quax nv
Karel Picquélaan 84
B-9800 Deinze
T
00 32 9 380 80 95
Parc enfant avec fond règlable
Playpen with adjustable bottom
