DIGITAL RADIO CONTROLS WITH ROLLING CODES S449
Description
The S449 Radio control system in "FM" consists of one or more transmitters
and one or more receivers which can be combined to meet the specific needs
of the system.
The S449 system uses a highly reliable encoding system guaranteed by the use
of dynamic codes. The code is changed for each encoding transmission through
the use of an encoding algorithm which only the receiver is able to recognise
and therefore decide whether or not the code transmitted corresponds to the
original code. The generated code is memorised in the receiver via radio. The
receiver is able to memorise up to 300 different codes.
The transmitted code changes for each command (rolling code). If disturbance
interrupts the transmission, the receiver will wait for a different code, the relay
can then only be activated by first releasing and then pressing the transmitter
channel button again.
Use
The S449 radio control allows the remote activation of electrical and electronic
appliances with its best use in the following areas: automatic opening systems,
alarm systems, and in all systems which require remote control activation (without
wires) using secret codes.
Transmitter versions
TRQ449100
Miniaturised transmitters
TRQ449200
Miniaturised transmitters
TRQ449300 Miniaturised transmitters
TRQ449400 Miniaturised transmitters
TRQ44940M Wall mounted transmitter
Receiver versions
RSQ449100 Slot-in receiver card (open collector output)
Antenna
The installation of the antenna is fundamental, connected to the receiver it
represents the reception point for the radio control. When installing the antenna
the following points should be observed:
A tuned antenna using a coaxial cable RG58 (impedance 50Ω) with a maximum
length of 15 m must be installed. The antenna should be positioned out of doors
in the highest possible point, visible and away from metal structures. It is good
practise to position the receiver away from computer systems, alarm systems
and other possible sources of disturbance.
Transmitters
The transmitter is pre-coded and is fitted with an integrated circuit which is
programmed in the factory with a unique identification number. All the code
parameters are contained in this integrated circuit (external memory modules are
not required) thus making code management more reliable and the system more
secure. The transmitter has an automatic shut down mechanism which cuts in
after at least 25 seconds of continuous use (this limits battery consumption).
• This time can vary from transmitter to transmitter.
Receivers
Warning! The receivers must only be powered by a safety power pack. The
use of non safety power packs could provoke damage to the system.
The receiver cards must be sufficiently insulated from the parts of the host
device which are powered by the mains.
The slot-in receiver card with "Pin-Strip" connections must be directly inserted into
the host appliance.
The radio reception part is made up of a 433 MHz RF module "R1" inserted in
the card.
The receiver has a single "open collector" output (contact 10 on the connector fig.
1). This output can be activated by any of the transmitter channels as long as they
have been memorised in the receiver.
Functions
A. Memorising a channel
B. Cancelling a channel (via an associated transmitter)
C. Cancelling the entire user memory
D. Memorising ulterior channels via radio (without having to open the box in
which the receiver is housed)
Attention! Before memorising the transmitters for the first time remember to
cancel the entire memory content.
+39/0438.404011-401818
+39/0438.401831
Sales.office.it@cardin.it
Sales.office@cardin.it
www.cardin.it
1 Button
2 Buttons
3 Buttons
4 Buttons
4 Buttons
1 Channel
SERIAL NUMBER
ZVL469.00
The S449 series conforms to the essential requirements of the directive 99/05/
CE and the technical reference standards have been applied.
Frequency validity: 433.92 MHz for all
A- Memorising a channel
1. Keep button "P1" MEMO pressed down and the led
"L1" will start to flash slowly
2. Press the channel on the transmitter which is to be
memorised
3. Keep button "P1" MEMO pressed down until led
"L1" starts to flash again
4. Release the button and the LED continues to flash
5. Press the channel on the transmitter which is to be memorised again (same
transmitter, same channel. If the channel or the transmitter is different you
will not be able to memorise the channel.
6. End of the memory procedure. LED "L1" will remain lit for 2 seconds meaning
that the channel has been correctly memorised.
• It is not possible to memorise a user code that is already in memory: In this
case when the transmitter is activated (point 2) the led will stop flashing. The
program will only work again when button "P1" MEMO has been released.
• If the transmitter is not activated a second time within fifteen seconds the
program will automatically leave the memory mode without memorising a new
user code.
• If a new user code is activated the first time and a different channel (with an
already memorised user code) is activated the second time, the program
will automatically leave the memory mode (because the two codes do not
correspond) and the channel present in the second transmission will be
activated.
B- Cancelling a channel
(fig. 1)
1. Keep button "P2" DELETE pressed down and the led "L1" will start to flash
rapidly
2. Press the channel on the transmitter which is to be cancelled
3. Led "L1" will remain lit for 2 seconds meaning that the channel has been
cancelled.
Note: If the user which is to be cancelled is not found in the memory, the led
will stop flashing. The program will only work again when button "P2" has been
released. If the button is released before a channel is activated the program will
automatically leave the memorising or cancelling mode.
C- Cancelling the entire user memory
1. Keep buttons (P1+P2) pressed down simultaneously for more than 4 sec-
onds
2. Led "L1" will remain lit for the period of time required for the program to cancel
all the codes (about 8 seconds)
3. Led "L1" will turn off meaning that the cancellation procedure has been carried
out.
Note: It is only possible to switch from memorising mode to cancelling mode
if you haven't already entered the second part of the memorising procedure
(point 4 onwards). Once this part of the procedure has been reached the entire
procedure will have to be completed. If you do not wish to memorise a code
which you have already transmitted wait for 15 seconds, the led will switch off
and the code won't be memorised. When the receiver's memory is almost full
the user search function can take up to 1 second to complete.
D- Memorising a channel via radio
• Memorisation can be activated by radio (without opening the receiver container)
if jumper "J1" has been inserted (fig. 1).
1. Make sure that the jumper "J1" has been inserted in receiver.
2. Using a transmitter, in which at least one channel button "A,B,C or D" has
already been memorised in the receiver, press the button "MR" as shown in
figures "1a, 1b".
Note: all the receivers within range when the channel button is pressed (and
which have at least one of the transmitter channel buttons memorised) will
activate their signal buzzer "B1" (fig. 1).
3. Press one of the channel buttons on the transmitter. The receivers which do
not contain that channel code will sound a five-second long "beep" and will
then disactivate.
The receivers which contain the channel code will sound a one-second long
"beep" and will enter the programming mode.
4. Press one of the channel buttons on the transmitter which you wish to memo-
rise; the receiver will sound 2 "beeps" of half a second each after which the
receiver will be ready to receive another code.
5. To leave the programming mode wait for 5 seconds without pressing any
buttons. The receiver will sound a five-second long "beep" and will then exit
the programming mode.
• When the memory is entirely occupied the buzzer will sound 10 rapid "beeps"
and will automatically leave the "programming via radio" mode.
Led "L1" will remain lit on the receiver. The same signal is given each time
you try to enter "programming via radio" when the memory is full.
SERIES MODEL
S449 FM 03-12-2004
countries
DEL
(fig. 1)
P2
(fig. 1)
(fig. 1, 1a, 1b)
DATE
MEMO
P1
L1
