8 Installing the FXFCH4, FXFCH16-C faucet
FXFCH4
3
4
5
6
7
8
9
18
9. Filtering cartridges
Type of cartridge
*depending on the quality of water and its contamination.
When using the system for the first time and after every replacement of cartridges
remember to rinse the system. Rinse time should be longer than 5 minutes. Next leave
the system for 5-6 hours to activate the filtering environment. After that you may start
drinking the water.
NOTICE! Cartridges are not covered with warranty in the following instances:
- the protective film is taken off,
- when the cartridges are being used.
12
FCPS20 Sediment filter for cold water. Used to filter potable and utility water - stops
sand, rust particles, suspended solids and contaminants contained in water with grain
size of 20 microns and more. A polypropylene spun cartridge improves organoleptic
parameters of water.
FCPS5 Sediment filter for cold water. Used to filter potable and utility water - stops
sand, rust particles, suspended solids and contaminants contained in water with
grain size of 5 microns and more. A polypropylene spun cartridge improves
organoleptic parameters of water.
FCCBL Purifying cartridge. Contains cemented carbon with high absorption of
chlorine and organic substances contained in water. The cemented carbon has
twice the active Surface and higher water filtering efficiency.
FCCA Purifying cartridge. Contains granulated carbon with high absorption of
chlorine and organic substances contained in water.
AICRO Cartridge with coconut shell carbon. Improves the taste and smell of water.
AIMRO Mineralizing cartridge. Enriches water with minerals essential for human
organism, such as calcium, magnesium, sodium, potassium.
TLCHF-2T - UF membrane removes most of bacteria and viruses not smaller than
0.02 micron.
P4-GT_K- UV lamp filament, removes bacteria harmful to the human organism from
the water. NOTICE!!! Sterilized water may be warm when collecting the first 0,5
litres. It is recommended not to drink the first batch of the filtered water.
Do not look at the UV light emitted by the lamp because this may damage the
eyesight.
AIFIR2000 2" ionizing cartridge, regulates pH of the organism, removes toxins,
ionized water is an excellent detoxicating agent.
RO membrane removes 96% - 99% of all pollutants from water (including some
bacteria and viruses).
1) To mount the faucet (fig.) drill two 12 mm holes in the kitchen worktop
or in the kitchen sink (in case of enamelled sinks the manufacturer
recommends drilling the holes in the construction supporting the sink).
Space between the holes - 18 mm.
2) Put a washer 2, and then a rubber seal 3 on the thread nozzle of the faucet.
3) Place the faucet in the previously drilled holes.
4) Place washers on the nozzle at the bottom side of the worktop (4,5) and screw
in with a nut (6).
5) Mount the tubing supplying water to the faucet. To do this, place metal nuts (9)
and plastic clamps (8) on the tubing and push inserts (7) into the tubing.
6) Slide the tubing (until it stops) inside the faucet nozzle and screw
it in (manually!) with a nut that was placed on the tubing earlier.
NOTICE: To seal the thread connections always use the pipe tape during an
assembly. Does not apply to threads for plastic nuts and for the faucet nuts
Description
Rinsing the system
NOTICE! When using the system for the first time and after every replacement of
filtering cartridges or the membrane remember to rinse the system.
Wait 60 minutes until the tank fills with water, then open the faucet valve and pour
the entire water out of the tank.
NOTICE! Do not drink this batch of water.
After rinsing, leave the system for 5 - 6 hours to activate the filtering environment,
then pour the entire water out of the tank again.
NOTICE! Do not drink this batch of water.
When completing the foregoing you may start drinking the filtered water.
Longevity*
Size
10" x 2 1/2"
3 - 6 months
(25 cm x 6,5 cm)
10" x 2 1/2"
3 - 6 months
(25 cm x 6,5 cm)
9 7/8" x 2 1/2"
3 - 6 months
(25 cm x 6,5 cm)
9 7/8" x 2 1/2"
3 - 6 months
(25 cm x 6,5 cm)
10" x 2"
6 - 12 months
(25 cm x 5,08 cm)
10" x 2"
6 - 12 months
(25 cm x 5,08 cm)
10" x 2"
6 - 12 months
(25 cm x 5,08 cm)
9000h
---
12 months
10,8" x 2"
6 - 12 months
(27,5 cm x 5 cm)
11,9" x 1,8"
up to 36 nonths
(30 cm x 4,5 cm)
