Lena Lighting UV-C STERILON FLOW 72W MONO Montageanleitung Seite 4

1A
POWER ON
1C
AIR
DISINFECTION
IN PROGRESS
2B CHANGING A UV-C TUBE
OPEN
OPEN
2D CHANGING A UV-C TUBE
6
UV-C STERILON FLOW 72W MONO - INSTALLATION INSTRUCTION
1B
ON/OFF
BUTTON
2A CHANGING A UV-C TUBE
POWER ON
Podczas wymiany świetlówek UV-C
używaj rękawiczek ochronnych
Use protective gloves when
replacing UV-C tubes
Verwenden Sie beim Ersetzen von
UV-C-Lampen Schutzhandschuhe
При замене УФ-ламп используйте
защитные перчатки.
2C
CHANGING A UV-C TUBE
DISCONNECT
2E CHANGING A UV-C TUBE
2F CHANGING A UV-C TUBE
2H CHANGING A UV-C TUBE
2J
CHANGING A UV-C TUBE
POWER ON
3B OPTION: HEPA FILTER
OPEN
OPEN
UV-C STERILON FLOW 72W MONO - INSTALLATION INSTRUCTION
2G CHANGING A UV-C TUBE
CONNECT
2I CHANGING A UV-C TUBE
OPEN
CLOSE
3A OPTION: HEPA FILTER
3C OPTION: HEPA FILTER OPTION: HEPA FILTER
DISCONNECT
7
