Connection cables

HDD LED M/B connector
POWER LED M/B connector
Reset S/W M/B connector
Power S/W M/B connector
You have the following options to connect fans in the case or to regulate the speed:
1. Slider on the top of the case
On the two sliders (see page 9) you can connect 1x one fan and 1x two fans with 3pin connection (see above).
The connected fans can be controlled by the slider in the speed "OFF", "50%" and "100%".
Illuminated fans can also be connected to the sliders. The lighting of additional fans can not be controlled without optional accessories (see product
homepage, section Accessories).
2. On the built-in RGB/PWM controller
On the built-in controller on the back of the mainboard carrier, up to 5 fans with 3-pin connection can be connected.
You can regulate the speed of the serial fans and 2 additional ones by connecting them to the controller. The controller will be connected to the
motherboard, this way your fans will be regulated depending on the temperature.

Fan connecting

4pin Molex power connector
for manual fan control.
3pin fan connector for
manual fan control.
1x
3x
10
