Manual IB-DK2512-TB3
Starting up
1. Plug in power supply
2. Connect the Thunderbolt 3 Type-C to Type-C cable to the Thunderbolt 3 Type-C inter-
™ ™ ™ ™ ™
face of your computer and to the Thunderbolt 3 Type-C host interface of the dock.
™ ™
You can also connect the DockingStation to a MFDP Alt Mode supported computer (non-Thunderbolt 3),
™
but with lower performance. When connected to a Thunderbolt 3 computer, it supports two 4K@60 Hz
™
displays and USB 3.1 (Gen 2) data throughput, while connecting to a non-Thunderbolt 3 USB Type-C
™ ™
computer allows it to support two 2K@60 Hz displays and USB 3.0 data throughput.
3. Connect your devices to the appropriate interfaces on the dock.
4. Switch on the device, as pictured above
