I Description of elements
14
7
11
9
16
21
20
15
18
27
1/ 3m Braided cable with USB-A
to USB-C connector
2/ Touch pad
3/ SHARE button
4/ OPTIONS button
5/ PS button
6/ Action buttons
7/ Left stick with L3 button
and 46° of amplitude
8/ Right stick with R3 button
and 46° of amplitude
9/ Directional pad
10/ LED player status indicator
3
10
24
26
11/ 4x Profile LEDs / Microphone,
Mute and Battery level indicator
12/ Headset connector (3.5mm jack)
13/ R1 Shoulder button
14/ L1 Shoulder button
15/ 2x Weight compartments
16/ R2 Analogue trigger
17/ L2 Analogue trigger
18/ Rear shortcut buttons
S1/S2/S3/S4
19/ Mode selection:
1. PS4™ Normal mode
2. PS4™ Advanced Mode
3. PC Advanced Mode*
1
2
12
23
22
20/
21/
22/
23/
24/
25/
26/
27/
13
4
6
5
8
17
19
15
18
25
Profile selection button
Communication Mode
1. Wired
2. Wireless
Microphone mute button/
Battery level (hold)
Volume DOWN
Volume UP
USB Plug & Play
Wireless receiver
Sync button
Sync LED
