GB
Ixion
User manual
Thank you for purchasing the planeo Ixion.
This document contains the required information for
correct, efficient and safe use of the product. Consult
the general manual of the 12-volt system
and the user manual of your transformer for more
information about the set up and connection of your
light plan.
Read the information in this manual carefully before
using the product. Keep this manual near the product
for consultation in the future.
PRODUCT DESCRIPTION
The planeo Ixion is a LED wall lamp for outdoor use.
The fixture can be fixed to the wall with the included
screws. This product may only be used as outdoor
lighting in combination with the planeo 12-volt system.
Any alterations made to the product may have
consequences for the safety, guarantee and correct
functioning of the product and/or other parts of the
system.
Specifications
Product
Article number
Power
Luminous flux
Dimensions (h x Ø)
Protection class
Ambient temperature
Cable length
Dimmable
INSTALLATION
Packaging content
[Figure A]
1. Fixture Ixion
2. Screws
3. Plugs
4. connector
5. Hex key
planeo Ixion
182W
9W
534 lm
110 x 110 x 110 mm
IP44
-20°C to 50°C
3m
Yes
Check if all parts are present in the packaging. For
questions about parts, service, and any complaints or
other remarks, you can always contact us.
E-mail: info@planeo.de
[Figure B]
Mount the back plate on the wall with the included
screws
If necessary, drill holes in the wall and use the
included plugs
[Figure C]
Place the lamp over the back plate
[Figure D]
Fasten the lamp with the included screws
[Figure E]
Determine the desired light angle by adjusting the
shutters
[Figure F]
Set the desired brightness using the push button
The brightness can be adjusted to 6 different levels
[Figure G]
Place the shade over the lamp
[Figure H]
Fasten the shade with the included screw
[Figure I]
Ready
7
