1.2 Specifications

Downloaded from www.Manualslib.com
Platform • Thin Mini-ITX Form Factor (Compatible with Mini-ITX)
• Solid Capacitor for CPU power
A-Style • Home Cloud
CPU • Supports 4
Pentium® / Celeron® processors with up to 65W TDP in an
LGA1150 package
• Supports Intel
®
Chipset • Intel
Memory • Dual Channel DDR3 Memory Technology
• 2 x DDR3 SO-DIMM Slots
• Supports DDR3 1600/1333/1066 non-ECC, un-buffered
memory
• Max. capacity of system memory: 16GB
(see CAUTION)
• Supports Intel
Expansion • 1 x PCI Express 2.0 x4 Slot
Slot • 1 x mini-PCI Express Slot
Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU integrated.
• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD
Technology, Intel® InsiderTM, Intel® HD Graphics 4400/4600
• Pixel Shader 5.0, DirectX 11.1
• Max. shared memory 1792MB
• Three graphics output options: HDMI, DVI-I and LVDS
• Supports HDMI Technology with max. resolution up to 4K ×
2K (4096x2304) @ 24Hz
• Supports DVI-I with max. resolution up to 1920x1200 @
60Hz
manuals search engine
th
Generation Intel® Core
®
Turbo Boost 2.0 Technology
H81
®
Extreme Memory Profile (XMP)1.3/1.2
H81TM-ITX
TM
i7 / i5 / i3 / Xeon® /
5
