Eaton Power Defense PDC-1 IEC Montageanweisung Seite 3

Breaker rotates 90° Left side
4a
2
3
Z1
1 Nm
(8.85 lb-in)
6
1
TEST
ON
Breaker rotates 90° Right side
4b
1
2
3
Z1
1 Nm
(8.85 lb-in)
2
2 mm
2 Nm
(17.7 lb-in)
1
TEST 2
TRIPPED
1
PUSH TO TRIP
5
TEST 3
OFF
EATON
IL012109EN
3
