3. General

The bottom edge angle (picture 2) defines how aggressive and direct the ski / snowboard will respond.
The smaller the angle the more aggressive and direct the response.
0,6° to 1,0°
- for racing
- personal tuning on event on skis
1,0° to 2,0°
- universal for regular skiing on the slope
- commercial Skis have 1,0° to 1,5°
- freerider and powder skis have 1,5° to 2,0°
In order to work correctly on the bottom edge the actual amount of degrees of the bottom edge must be
known. The BASEMAN measures the bottom edge angle precisely to 0,01 degrees.
IMPORTAINT: Material which has been already removed cannot be undone anymore. For
instance, if material is grinded to 1.5 degrees, one cannot anymore grind back to 1.0 degrees
!
(the material is no longer available).
This can only be corrected by levelling of the ski/snowboard via machine.

4. Preparation

1. Remove battery safety foil
2. Loosen the allen screw with the allen key (included in the delivery), picture.3.1
3. Insert the lamp holder and fix it with allen key, picture.3.3
4. Insert LED- lamp ...
5. ... and check functionality through clockwise turning, picture.3.2
1
picture 3
picture 2
2
3
