Safety Instructions

Before putting the PROmesh P10 into operation, check whether it is in perfect condi-
tion externally. Always observe the technical specifications of the device to ensure safe
and optimal use. The PROmesh P10 is designed for IP30 protection environments. Take
appropriate measures to ensure proper operation of the unit in a different environment.
! WARNING In case of suspected damage, please return the PROmesh P10 immediately to your
supplier and do not put it into operation.
Do not open the housing under any circumstances. Unauthorized opening of the
housing will void any warranty claims.
The PROmesh P10 is designed for use in PROFINET applications according to Confor-
mance Class B.
For complete support of the PROFINET standards, please also observe the selection,
layout and wiring of the data ports according to these standards.
Scope of Delivery
• PROmesh P10
• 7-pole 5mm terminal block (power supply and alarm contact)
• Quickstart User Guide (hardcopy)
• USB-Stick containing the following files: Manual (PDF), Quickstart User Guide
(PDF), Service Tool (ZIP), Switch Video (MP4)
• SD Card, can be used for backup and updates
Mounting on the DIN Rail
Mount the PROmesh P10 upright in the switch cabinet on a 35mm DIN rail (DIN EN
60715).
! NOTE
The following distances to other modules must be observed:
• right / left: 50 mm
• top / bottom: 50 mm
ENGLISH
! WARNING
Power Supply
Configuring a Network
Connection
! NOTE
11
Do not mount the PROmesh P10 directly next to devices that generate strong electro-
magnetic interference fields or constantly emit heat to their surroundings. Also protect
the PROmesh P10 from intense sunlight.
The PROmesh P10 is operated with a redundant DC voltage of 12-36VDC, Connect a
suitable power source to the labeled terminals of the 7-pin 2,5mm
Connect the positive lead to one of the VDC contacts and the ammunition lead to the
corresponding GND contact.
If the external power supply is correctly connected and activated, all status LEDs of the
PROmesh P10 will light up briefly. After a short initialization phase the LEDs go out and
the device is ready for operation and can now be configured in the network.
Download the Service Tool to your client PC (Windows). You can find the software on
the enclosed USB-stick or on our website:
www.indu-sol.com/en/servicetool
Our software is updated regularly. Please, make sure you are using the latest version.
Connect the PC to a suitable data line on one of the data ports (P1-10).
The PROmesh P10 and the client PC must be located in the same IP address range and
IP subnet. For this you have to assign a corresponding IP address to your PROmesh P10
for the first time. Use the already installed ServiceTool.
After assigning a suitable IP address and subnet mask, the Web UI of the PROmesh P10
can be reached.
The PROmesh P10 is delivered with the following factory settings:
ENGLISH
2 terminal block.
