Names Of The Parts - nemaxx VKM0325LED Originalbetriebsanleitung

ANWING UNIT
1
9
8
7
1. Cover
2. Cassette
3. Awning motor (built-in)
4. Hinged arm
5. Fabric
6. Front cover
7. Hinged arm bracket
8. Wall bracket
9. Connection cable
10. LED strip
REMOTE CONTROL
1. Extending
2. Stop button
3. Retracting
4. Indicator light
5. The switch of LED light (ON/OFF)
6. Wall mount base
7. Battery compartment ( for 3V battery)
8. P2 button
