Translation of the original instructions
• Clean the device's surfaces with a soft, dry cloth.
Regulations :
• The device complies with European Directive.
• The certificate of compliance is available on our website."
• EAC conformity mark (Eurasian Economic Commission)
• Equipment in conformity with Moroccan standards.
• The declaration C‫( م‬CMIM) of conformity is available on our
website (see cover page).
Disposal:
• This product should be disposed of at an appropriate recycling
facility. Do not dispose of in domestic waste.
DESCRIPTION
The MSW 82000 inverter is a product that converts DC electricity to AC electricity to provide the power needed to
operate small electrical equipment and digital products. It is widely used in cars, boats, mobile offices, post and tele-
communications, public safety, emergencies, and so on.
This inverter has adopted the internal electronics of this Power Inverter follow the pilot circuit international standard
with the benefits of being small, light, stable and with a high conversion efficiency. It includes five functions: low input
voltage protection, input overvoltage protection, overload protection, overtemperature protection, output short-circuit.
These five functions protect the vehicle's power supply, the equipment and the vehicle's circuit.
PRODUCT INTERFACE
2
1
4
1 DC current input -Terminal "-" (Black)
2 Fan
3 DC current input - Terminal «+» (red)
4 Power indicator (green)
MSW 82000
3
7
5 Fault indicator (Red)
6 AC output sockets
7 ON / OFF switch
8 USB output
EN
6
5
8
7
