2. DESCRIPTION AND CORRECT USE OF THE DEVICE

Digibell is an electronic device for door unlocking with the use
of a remote control, which combines a remote control receiver
and a doorbell key and a wireless doorbell.
The device is installed into a door wing with the receiving unit
with the doorbell key on the outer side of the door and the
relay unit with two relays within the door profile. A part of the
device is also a wireless doorbell, which can be plugged into
any socket (220V) in the house, and a transmitter for the do-
orbell, which is placed next to the power supply of the device
in the electric cabinet.
The device can be operated only with the original remote
controls, which can be purchased additionally from the distri-
butor of the device. The doorbell key is triggered by a gentle
press of a finger on the doorbell icon. It is not allowed to press
intensely or use objects that could damage the surface of the
device for its triggering.
The doorbell is attached to a standard 220V 50 Hz EU socket.
If the device is not energised, it will not work. The maximum
distance between the doorbell and the doorbell transmitter is
60m without obstacles.

3. REMOTE CONTROL AND UNLOCKING DOORS

The device is equipped with two remote controls. Both of
them are already paired with the device and you can unlock
doors with any of them. Both remote controls have four keys.
•
Press the key A for 1s to trigger relay no 1, which is con-
nected to the electric lock in the door with the installed
Digibell. The door unlocks after 1s.
•
Press the key B for 1s to trigger relay no 2. If another door or
device is connected to this relay, it will open after 1s.
•
A green LED is turned on and a 1 x 1s beep is emitted.
•
Press the key C or D to trigger the doorbell in the house.
The remote control's range is 10m. The remote control is
supplied by a 12V battery, when the battery is dead, the remo-
te control stops working. When the battery is low, the range
of the remote control becomes a bit shorter or the key needs
to be pressed repeatedly for the receiver to detect the signal.
This is a sign that the battery should be replaced.
4
digibell
Changing the battery of the remote control:
The battery can be changed in any specialised store that sell
batteries or you can order it from the distributor of the device.
To change the battery unscrew the screws on the back side
of the remote control, open the remote control, then take the
old battery out and replace it with a new one. It is necessary
to make sure that the battery terminals (+ and -) are put to
the correct side. After that, close the remote control and screw
back the screws.
Rolling code:
The rolling code is a code, transmitted by the remote control.
When it is paired with the device, the remote control and the
transmitter exchange the key, upon which the code is chan-
ging. Every time you press any button on the remote control,
a signal containing the rolling code is transmitted, the code is
different every time.
If the receiver is out of range, when you press a remote control
button, the emitted signal is lost. This can happen up to 50
times. After that, the key is lost and the remote control is no
longer paired with the receiver. This is why it is necessary to
be careful not to press the remote control buttons, when
it is out of the range of the receiver!
Pairing a new remote control with the receiver:
When a new remote control needs to be paired or an existing
remote control needs to be paired again, this must be done by
following the next procedure:
•
Unscrew the electric safety bolt of the door and pull out the
relay unit from the door profile.
•
Press the button on the relay unit for 10s.
•
After 10s the device emits a beep, after which you have 10s
time to pair the remote control. After each remote control
being paired the time is prolonged by 10s.
•
Press any remote control button for 1s.
•
The device emits a beep and the remote control is now
paired.
Note:
The device can be paired with up to 60 remote controls. If the
device is already paired with the maximum number of remote
controls or a remote control is lost and a new one needs to be
paired, you must erase the entire remote control base and pair
