CUB 300HD
Parts Book
Ersatzteile
Lista de Repuestos
Liste de Pièces de Rechange
www.wackerneuson.com

Werbung

loading

Inhaltszusammenfassung für Wacker Neuson CUB 300HD

  • Seite 1 0620253 05.2010 Portable Indirect Air Heaters Fahrbare Kaminheizgeräte Calentadores de aire indirectos portátiles Réchauffeurs indirects d'air (portatifs) CUB 300HD Parts Book Ersatzteile Lista de Repuestos Liste de Pièces de Rechange www.wackerneuson.com...
  • Seite 3 Nameplate CUB 300HD Typenschild Plaque signalétique Placa de Identificación A nameplate listing the Model Number, Item Number, Revision, and Serial Number is attached to each unit. Please record the information found on this plate so it will be available should the nameplate become lost or damaged. When ordering parts or requesting service information, you will always be asked to specify the model, item number, revision number, and serial number of the unit.
  • Seite 4 Part Numbers - Boldface CUB 300HD Fettgedruckte Artikelnummern Números de partes en negritas Numéros de pièce - en caractères gras Part Numbers appearing in boldface type are recommended spare parts. This means that these parts are subject to wear under normal operating conditions and may require periodic service or replacement.
  • Seite 5 Table of Contents CUB 300HD Inhaltsverzeichnis Indice Table des matières Heater Heizung Calentador Réchauffeur Frame/Components Rahmen/Bestandteile Chasis/Componentes Châssis/Composants Labels Aufkleber Calcomanias Autocollants 0620253 - 105...
  • Seite 6 Heater CUB 300HD Heizung Calentador Réchauffeur 0620253 - 105...
  • Seite 7 Heater CUB 300HD Heizung Calentador Réchauffeur Measurem./Abm. Norm Ref. Part No. Qty. Description Descripción Pos. Artikel Nr. Beschreibung Description Sealant Torque/Drehm. Schmierstoff Ventilador 0172597 Gebläserad Ventilateur Motor-fan Motor-ventilador 0172598 Motor, Lüfter Moteur - ventilateur Adapter fan Ventilador adaptador 0172092 Adapter, Lüfter...
  • Seite 8 Heater CUB 300HD Heizung Calentador Réchauffeur 0620253 - 105...
  • Seite 9 Heater CUB 300HD Heizung Calentador Réchauffeur Measurem./Abm. Norm Ref. Part No. Qty. Description Descripción Pos. Artikel Nr. Beschreibung Description Sealant Torque/Drehm. Schmierstoff Reset-pushbutton Restablecimiento-botón 27 0170287 Rückstellungsdrucktaste Réinitialisation - bouton - poussoir Plug-thermostat Tapón-termostato 28 0172109 Stecker, Temperaturregler Fiche - thermostat...
  • Seite 10 Heater CUB 300HD Heizung Calentador Réchauffeur 0620253 - 105...
  • Seite 11 Heater CUB 300HD Heizung Calentador Réchauffeur Measurem./Abm. Norm Ref. Part No. Qty. Description Descripción Pos. Artikel Nr. Beschreibung Description Sealant Torque/Drehm. Schmierstoff Stack-flue Tubo-cañón 70 0172140 Schacht, Luftklappe Cheminée - conduit Clip-cover Sujetador-tapa 71 0172141 Klemme, Abdeckung Couvre - attache...
  • Seite 12 Frame/Components CUB 300HD Rahmen/Bestandteile Chasis/Componentes Châssis/Composants 0620253 - 105...
  • Seite 13 Frame/Components CUB 300HD Rahmen/Bestandteile Chasis/Componentes Châssis/Composants Measurem./Abm. Norm Ref. Part No. Qty. Description Descripción Pos. Artikel Nr. Beschreibung Description Sealant Torque/Drehm. Schmierstoff Upper frame Chasis superior 0173663 Oberer Rahmen Châssis supérieur Fuel tank Depósito de combustible 0173665 Kraftstofftank Réservoir de carburant Lifting bracket Ménsula alzadora...
  • Seite 14 Frame/Components CUB 300HD Rahmen/Bestandteile Chasis/Componentes Châssis/Composants 0620253 - 105...
  • Seite 15 Frame/Components CUB 300HD Rahmen/Bestandteile Chasis/Componentes Châssis/Composants Measurem./Abm. Norm Ref. Part No. Qty. Description Descripción Pos. Artikel Nr. Beschreibung Description Sealant Torque/Drehm. Schmierstoff 1/4 x 3/4in Fender washer Arandela 512 0167806 Unterlegscheibe Rondelle M8 x 20 Hexagonal flange head screw Tornillo hexagonal de brida...
  • Seite 16 Labels CUB 300HD Aufkleber Calcomanias Autocollants 0620253 - 105...
  • Seite 17 Labels CUB 300HD Aufkleber Calcomanias Autocollants Measurem./Abm. Norm Ref. Part No. Qty. Description Descripción Pos. Artikel Nr. Beschreibung Description Sealant Torque/Drehm. Schmierstoff Label -logo Calcomanía -logotipo 0176654 Aufkleber, Logo Autocollant - logo Label-warning Calcomania-Advertencia 0176655 Aufkleber-Warnung Autocollant-Avertissement Label-instruction plate Placa-instrucciones...
  • Seite 18 Neuson Corporation 9007 Menomonee Falls, 53052-9007 Tel.: (262)-255-0500 Fax: (262)-255-0550 Wacker Neuson Ltd. - Tower 1, Grand Century Place - 193 Prince Edward Road West - Mongkok, Kowloon - Hong Kong, VR China - Tel: +852-3605 5360, Fax: +852-2406 6021...
