Applications
-HVAC/Building Controls
-Poultry House Automation
-Greenhouse Automation
-Food Factaries and Warehouses
-Cold Storage
-Pharmaceutical
-Air Conditioning Automation and Air Conditioners
-Textile Applications
-Clean Rooms and Laboratory
Electrical Connections
ATTENTION: Only 4-20 mA type, temperature output must always be connected to
the power supply's negative pin!
Downloaded from
www.Manualslib.com
Current
(4-20mA)
Transmitter
Temp. out
RH out
(Yellow)
(Green)
4
3
+
mA
mA
Voltage
(0-10V)
Transmitter
Temp. out
RH out
(Yellow)
(Green)
6
5
+
+
V
V
manuals search engine
V in
(Brown)
1
+
+
-
V-
V+
(White)
(Brown)
2
1
DC
Power
Supply
+
DC
Power
-
Supply
