ATTENTION!
ALWAYS USE AN OIL-MOISTURE SEPARATOR WHEN USING REMOTE
CONTROL SYSTEM TO PREVENT WEAR ON RC VALVE.
BESIDES, AN OIL-MOISTURE SEPARATOR OPTIMIZES ABRASIVE BLASTING
OPERATIONS.
7.
Ensure that compressor is positioned out of the abrasive blasting operations zone on
downwind side.
8.
Start compressor and increase pressure and temperature up to operational values.
9.
Open the ball valve at machine compressed air line (the handle of the open valve
should be parallel to the compressed air line).
10.
Open the safety ball valve 14 (Fig.2.1).
11.
Close metering valve FSV-0 by setting adjusting handle in the central position.
12.
Connect compressed air hose to hose coupling of the machine. Compressed air hose
diameter should be at least 1/ 2". Lock hose coupling with a safety clip or wire.
13.
Connect abrasive blasting hose to hose coupling of the machine. Lock hose coupling
with a safety clip or wire.
14.
Fill the machine tank with abrasive.
15.
Put protective equipment on.
8
