Set The Alarm Signals Of The Receiver; Call Repeat; Date & Time; Saving Power (Power Save Mode) - CSS AssistX Mobil Gebrauchsanweisung

30 | Instructions for Use
AssistX Mobil
• Delete of subscribers
Go to „Menu > Subscribers > Delete". You can now select subscriber to
be deleted from the subscribers list and delete them with the [OK] key.
If you delete a subscriber having a standard name like „Caller 4", the re-
maining list will be shrinked. means: „Caller 3" will be followed by „Caller
5". A new transmitter will have the name „Caller 4". To delete all trans-
mitters go to „Menu > Subscribers > Delete all".
Note: For safety reasons we recommend in larger facilities to use two
devices for each receiver used so that one is always charged and one is
used. This guarantees the battery life for one shift.

Set the Alarm signals of the receiver

The receiver is able to emit four different alarm signals: Sound / Flash / Vibra-
tion / Relay (switch, toggle)
The switch output can activate e.g. external call signals.
9
• Aktivate/deactivate Alarm signals
Go to „Menu > Settings > Alarm Signals". Here the signals can be set
separately.
• Set the switch mode
Trough „Menu > Settings > Relay Mode" the switch mode can be set up.
Relay Mode
1x 1 sec

Call repeat

Here the time can be set when a call should be triggered again if the call has
not been finally confirmed at the caller. This function cannot be deactivated
(safety function!). We strongly recommend settings to 1 min.
continious Interval
Date & Time
Notice: the actual week day will be showed and automatically adjusted and
can't set manually.
• Call up time menu
Go to „Menu > Settings > Clock > Clock Set".
• Set Clock
The navigation is controlled via [+] and [-].
• Daylight saving time
Here the automatic changeover to daylight
saving time can be switched on and off.
• Save and exit
Press the [OK] key 1 sec for „Next".
Use [OK] to go back to menu.

Saving power (Power save mode)

If the Power save mode is switched on the display will switch off after 20 sec
after the last key press. By pressing the [OK] button the display will switch on
again.
If there is an alarm or an out of range warning the display will switch on
6 5
and will stay on as long as there is an alarm or warning.
• Activate/deactivate power save mode
Go to „Menu > Settings > Power Save".

Infared receiver of the transmitter

An infrared receiver is built into the transmitter. With a AAC or environment
control device, a call can be triggered via a built-in transmitter. This function
can be used in addition to a sensor/switch. The IR receiver is activated by de-
fault. It can be switched off (e.g. if there are several transmitters in the room)
by first pressing the ON button (3), then the red button (6). After a short time,
the LED around the red button lights up red, then the IR receiver is deactiva-
ted. When the process is repeated, the LED turns green and the IR function is
activated again.
| 31
Instructions for Use
AssistX Mobil
(From Firmware V1.34 & Device Version V1.08)
EN
