18 | Instructions for Use
AssistX Mobil Repeater

8. Use of the device

Required for operation: The firmware on all components in the system
(transmitters, receivers and repeaters) must be the same, at least V1.34!

Installation:

Screw the antenna onto the
AssistX Mobile Repeater
Wall mounted:
Then plug the supplied power supply into the socket and connect it to the
repeater at the USB socket.
3
Switch on the repeater by pressing the
The LED lights up and you will hear one or more beeps.
4
LED shows the charging status (red, yellow, green). If the
The 4
green, the internal buffer battery (emergency power supply) is fully charged.
This should always be the case in normal operation. The
repeater's radio activity by flashing blue.
LED flashes orange or red, please check the power supply and
If the
4
the socket. The repeater is then no longer charged and runs on battery
power (emergency operation)! A out-of-range alarm on one of the re-
ceivers used can also indicate a power supply problem on the repeater!
and align it:
Table top:
2 On/Off button for approx. 3 seconds.
4 LED lights
LED also shows the
4
Signal Display
Normal operation, power supply connected
4
flashing: Emergency operation, Battery 100%
flashing: Emergency operation, Battery 50%
flashing: Emergency operation, Battery 10%
flashing: Radio activity of repeater

Using several repeaters:

If you are using more than one repeater, do not switch them on at the same
time. Please wait approx. 20 seconds between switching on. The repeaters or-
ganize themselves automatically and assign themselves an identifier, which you
can recognize by the number of beeps when switching on (1x to 8x). If you try
to install more than 8 repeater, you will hear a warning sound from the 9th on.
If you need to switch off one or more repeaters during operation (press the
On/Off button for longer than 3 sec) e.g. to change the location, it is not critical
in which order you switch back on the devices, the correct initialization takes
place automatically. This is also the case if you need to replace a repeater.
By pressing the On/Off button for 1 sec, the repeater is restarted and
initialized automatically.
If you want to use the wall mount, mount it to the wall using the screws provi-
ded. The repeater then only has to be pressed into the wall mount, it is held in
place magnetically.

9. Settings

No settings are necessary or possible on the repeater. If the device is in an un-
defined state, you can very carefully press the
with a paper clip or a similarly thin object. The repeater restarts and automati-
cally configures itself as described above.
| 19
Instructions for Use
AssistX Mobil Repeater
2
Reset Button (behind a hole)
5
EN
