4.2

Electrical data

Rated voltage
(See approvals for
limit values)
Operation voltage
range
Rated current (max)
Power consumption
(max)
5.

Approvals

(Approvals are valid for marked devices)
UL, cUL E189090
In preparation UCST, UCST7, ULSZ, ULSZ7, UEES, UEES7
04/2020
12 – 48V DC
10 – 60 V DC
12 V DC 24 V DC 48 V DC
275 mA 120 mA 65 mA
3.3 W 2.9 W 3.1 W
Operating instructions PY L-S
24 V AC
50/ 60 Hz
21.6 – 26.4
V AC
120V DC
167 mA
74.4 mA
2.93 mA
4 VA
Page 3 / 7
115 - 230 V AC
50/ 60 Hz
120V DC
90 – 265 V AC
108 -132V DC
115V AC 230V AC
51 mA 36 mA
5.9 V 8.3 VA
