Item name
A POWer leD
ethernet link/
B
Activity leD
c Plc link/Activity leD
D GrOUP Button
e reset Button
f ethernet connection
Powerline Adapter
Description
On: Power on.
BlInKInG:
1. (blink at slower rate) means Standby mode, or
2. During Group pairing procedure. In this procedure, the device joining or being
joined into same logical network will continue 2 minutes' blinking, until the pro-
cedure succeeds or is canceled). To enter or cancel Group pairing procedure, just
press the GROUP button 2-3 sec.
Off: Power off.
On: Ethernet Link Detected.
BlInKInG: Ethernet traffic detected.
Off: No Ethernet Link detected.
On: Powerline Link detected but no powerline traffic.
BlInKInG:
1. fast blinking (0.06 s ON/ 0.06 s OFF):
Powerline data rate higher than 60 Mbit/s.
2. normal blinking (0.2 s ON/ 0.2 s OFF):
Powerline data rate between10Mbps to 60 Mbit/s.
3. slow blinking (1 s ON1/ 1 s OFF):
Powerline data rate slower than 10 Mbit/s.
Off: Powerline Link not detected (either other devices in same network is too far
to communicate or it is alone in its logical network).
Press 10 seconds: clear the current and randomly generate a new network group
name.
Press 2 to 3 seconds: this will enter Group pairing procedure. In this procedu-
re, the device starts joining into a logical network of other device or announcing its
network group name for other devices to join. This maximum two-minute procedu-
re automatically ends when it succeeds or is manually stopped. Press this button 2
to 3 seconds will manually stop the procedure.
Press the button when the device is powered on (not standby) to recover all Facto-
ry default settings (including Plc network group name).
Every new PLC devices' factory default Plc network group name is
homePlugAv. During trouble shooting powerline network communication and
network group assignment, doing this to every PLC devices will make each device
return to default network group, thus ensure their mutual communicability.
RJ45 interface
