EX-1147HMVS English
3. Layout, Connections & Jumper Settings

3.1 Layout

Power LED 7-48V DC-Connector for
optional external Power Supply
7-48V T-Block for optional 7x USB 3.2 (Gen1) 1x USB 3.2 (Gen1)
external Power Supply Downstream C-Port Upstream C-Port

3.2 Connections

+7V - 48V T-Block:
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
GND (Ground)
+7V - 48V
7-48V DC-Connector:
ATTENTION!!!
Never plug in with force.
© Copyright 2020 by EXSYS Vertriebs GmbH. All Rights Reserved
9
