Motherboard Layout Motherboard Layout Motherboard Layout Motherboard Layout Motherboard Layout
1 PS2_USB_PWR1 Jumper
2 ATX 12V Connector (ATX12V1)
3 775-Pin CPU Socket
4 CPU Fan Connector (CPU_FAN1)
5 2 x 240-pin DDR3 DIMM Slots
(Dual Channel: DDR3_A1, DDR3_B1; Blue)
6 2 x 240-pin DDR3 DIMM Slots
(Dual Channel: DDR3_A2, DDR3_B2; White)
7 ATX Power Connector (ATXPWR1)
8 TPM Header (TPM1)
9 IDE1 Connector (IDE1, Blue)
10 Chassis Fan Connector (CHA_FAN1)
11 Clear CMOS Jumper (CLRCMOS1)
12 Power Fan Connector (PWR_FAN1)
13 System Panel Header (PANEL1, White)
14 Fourth SATAII Connector (SATAII_4; Blue)
15 Third SATAII Connector (SATAII_3; Blue)
16 Primary SATAII Connector (SATAII_1; Blue)
17 Secondary SATAII Connector (SATAII_2; Blue)
2 2 2 2 2
ASRock G41M-GE3 Motherboard
manuals search engine
18 Chassis Speaker Header (SPEAKER 1, White)
19 Chassis Intrusion Header (CI1)
20 BIOS SPI Chip
21 USB 2.0 Header (USB4_5, Blue)
22 USB 2.0 Header (USB6_7, Blue)
23 South Bridge Controller
24 Serial Port Connector (COM1)
25 Floppy Connector (FLOPPY1)
26 Print Port Header (LPT1, White)
27 Infrared Module Header (IR1)
28 Internal Audio Connector: CD1 (Black)
29 Front Panel Audio Header
(HD_AUDIO1, White)
30 PCI Slots (PCI1- 2)
31 PCI Express x16 Slot (PCIE2)
32 PCI Express x1 Slot (PCIE1)
33 North Bridge Controller
