QUICK GUIDE
Start the test.
In the Smart Status page all ATM and AAL-5 levels statistics are measured and
displayed, for a complete line report.

3.10. Background Monitor

The following example describes the setup for ADSL monitoring.
Open the TEST MENU.
Select ADSL Access, ATU-R mode.
Select MANUAL TESTS.
Select BACKGROUND MONITOR and open the SETUP
MONITOR screen.
Parameters configuration.

3.10.1. Start monitoring

When you have set the filters, you can start the monitoring test.
Select "Use this setup for monitoring", connect the instrument as indicated and
press START.
Start monitoring.

3.10.2. Stop monitoring

Before saving the trace you need to stop monitoring.
D2061 ADSL TESTER
31
