QUICK GUIDE
Select MANUAL TESTS.
Select ATM PING menu.
Parameters configuration.
The display shows the Test Status (running or not) and the ADSL link status.
The LED STATUS is OFF if no test running, is ON (solid green) during
►
regular test running.
The LED LINK is OFF if the physical connection is not active, is ON (solid
►
yellow) during the connection phase, is ON (solid green) when the
connection is active, is ON (solid red) when an error occurs.
Define the following parameters to perform the test:
Cell type: Select the type of traffic to simulate:
•
F5 end to end, OAM F5 cell type used for controlling the entire connection
(end to end).
•
F5 segment, OAM F5 cell type used for controlling a single segment of the
connection.
•
F4 end to end, OAM F4 cell type used for controlling the entire connection
(terminal - exchange).
•
F4 segment, OAM F4 cell type used for controlling a single segment of the
connection (terminal - exchange).
VPI: Virtual Path Identifier, default value is 8, on which flows the required traffic.
VCI: Virtual Channel Identifier, default value is 35, on which flows the required
traffic.
Location ID: Enter the ID address, made by hexadecimal octets, necessary for
identifying and controlling a single segment of the connection. Only F4/F5
segment.
Ping request number: Insert the number of Ping (Echo) requests.
Max response time (sec): Maximum response time between Ping requests. The
test set waits this time before considering the request expired.
