DigiLevel Pro 40/60/80
7 a c
b
READ
REF CAL
SET
24 25 26 27 28
m
11
12
13
11
14
e g i a
d f h
DigiLevel Pro
29 30 31 32
l k j
1 ON/OFF button / READ: Transfer
measured data via Bluetooth
interface
2
Angle reference value setting /
3 sec.: change sensitivity
3
Set gradient function
4
Laser ON/OFF
5
Change units of measure
6
Acoustic signal generator ON/OFF /
Hold function
7
Calibration
a
Slope direction
b Bluetooth
®
c Gradient function set
d HOLD: current measured
value is held
e Unit of measurement %
f Digital bubble level
g Unit of measurement mm/m
h Angle reference set
i
Battery charge
j Unit of measurement ° degrees
k Acoustic signal generator active
l
Slope angle
m Laser active
8
Horizontal vial
9 Vertical vial
10 Laser outlet
11
Magnets
12 Battery compartment (Rear)
13 Measuring surface
14
Measuring scale
(DigiLevel Pro 40 / 60 only)
%
mm/m
HOLD
