Follow instructions of cable gland or conduit fi tting manufacturer
en
Vorgaben des Kabelverschraubungsherstellers beachten
de
Suivre les instructions du fabricant de presse-étoupe
fr
OBS! Följ instruktionerna från tillverkaren av kabelinförningsmaterial
sv
Seguire le istruzioni del produttore dei pressacavi
it
Seguir las instrucciones del fabricante del racor con rosca para cables
es
请遵守电缆密封接头制造商的规定
cn
Соблюдайте инструкции изготовителя кабельного резьбового соединения
ru
ø
ø
4 ... 6.5 mm
0.16 ... 0.26"
IB132
en Plane surface
de Ebene Fläche
Surface plane
fr
sv Plan yta
Superfi cie piana
it
es Superfi cie plana
cn 平面
ru Ровная поверхность
2 x 5 mm
MS116 / MS132 / MO132
4 x Pozidriv 2
1.0 Nm
8.85 lb.in
Ie
≤ 10.5 A
MS116-12
≤ 12.0 A
MS116-16
≤ 15.5 A
≤ 10.5 A
MS132-12
MO132-12
≤ 11.0 A
≤ 14.0 A
MS132-16
MO132-16
≤ 15.0 A
≤ 17.5 A
MS132-20
MO132-20
≤ 19.5 A
≤ 22.0 A
MS132-25
MO132-25
≤ 23.5 A
MS132-32
≤ 27.5 A
MO132-32
UL/CSA limitations
Max. Short Circuit Ratings for MS116/MS132 with Enclosure IB132:
30,000 A rms, 480 VAC for the current ranges 0.16 – 2.5 A
18,000 A rms, 480 VAC for the current ranges
5000 A rms, 600 VAC for the current ranges 0.16 – 10 A
Use of MS132 as Combination Motor Controller, Type E not permitted.
118
4.65"
I ON
0
OFF
IP65
IP44
1x SK1/HK1/CK1
1x UA1/AA1
1x HKF1
Iq
( 400 V AC )
1.5 mm²
16 kA
2.5 mm²
13 kA
4.0 mm²
10 kA
1.5 mm²
13 kA
2.5 mm²
13 kA
2.5 mm²
16 kA
4.0 mm²
13 kA
2.5 mm²
10 kA
4.0 mm²
8 kA
4.0 mm²
8 kA
6.0 mm²
7 kA
6.0 mm²
7 kA
4.0 – 10 A
Pozidriv 2
1.2 Nm / 10.62 lb.in
2 x 1.5 ... 6 mm
2
AWG 16 ... 10
2 x 1.5 ... 4 mm
2
AWG 16 ... 12
119
4.69"
mm inch
H
O
IP44
2
2CDC131028M6804b / 06.2014
