Before

charging

While charging Lights

Charging

Pilot

complete

lamp

(red)

Charging

impossible

Overheat

standby

● Regarding the temperatures and charging time of the battery.

The temperatures and charging time will become as shown in Table 2.

Type of battery

Temperatures at which the

battery can be recharged

Charging voltage

Battery

Charging time,

approx. (At 20°C)

NOTE

The recharging time may vary according to the ambient

temperature and power source voltage.

CAUTION

When the battery charger has been continuously used,

the battery charger will be heated, thus constituting

the cause of the failures. Once the charging has been

completed, give 15 minutes rest until the next charging.

4. Disconnect the charger's power cord from the

receptacle.

5. Hold the charger ﬁ rmly and pull out the battery.

NOTE

Be sure to pull out the battery from the charger after use,

and then keep it.

CAUTION

○ If the battery is charged while it is heated because it has

been left for a long time in a location subject to direct

sunlight or because the battery has just been used,

the pilot lamp of the charger lights up green or lights

for 1 second, does not light for 0.5 seconds (oﬀ for 0.5

seconds). In such a case, ﬁ rst let the battery cool, then

start charging.

○ When the pilot lamp ﬂ ickers in red (at 0.2-seconds

intervals), check for and take out any foreign objects in

the charger's battery connector. If there are no foreign

objects, it is probable that the battery or charger is

malfunctioning. Take it to your authorized Service

Center.

Indications of the pilot lamp

Lights for 0.5 seconds. Does not light for 0.5

Blinks

seconds. (oﬀ for 0.5 seconds)

Lights continuously

Lights for 0.5 seconds. Does not light for 0.5

Blinks

seconds. (oﬀ for 0.5 seconds)

Lights for 0.1 seconds. Does not light for 0.1

Flickers

seconds. (oﬀ for 0.1 seconds)

Lights for 1 second. Does not light for 0.5

Blinks

seconds. (oﬀ for 0.5 seconds)

Charger

14.4

BSL14xx series

(4 cells)

BSL1415S : 20

BSL1415 : 22

BSL1415X : 22

min.

BSL1420 : 30

BSL1425 : 35

BSL1430C : 45

Table 1

Table 2

UC18YFSL

Li-ion

0°C – 50°C

BSL18xx series

(8 cells)

(5 cells)

BSL1815S : 20

BSL1430 : 45

BSL1815 : 22

BSL1440 : 60

BSL1815X : 22

BSL1450 : 75

BSL1820 : 30

BSL1460 : 90

BSL1825 : 35

BSL1830C : 45

○ Since the built-in micro computer takes about 3 seconds

to conﬁ rm that the battery being charged with chargers

are taken out, wait for a minimum of 3 seconds before

reinserting it to continue charging. If the battery is

reinserted within 3 seconds, the battery may not be

properly charged.
