PARTS LIST

KEY
NO. DESCRIPTION
1 Right Upright
2 Left Upright
3 Right Base
4 Left Base
5 Cross Brace
6 Main Seat Support
7 Front Post
8 Front Base
9 Backrest Adjustment Bar
10 Main Seat Stabilizer
11 Sliding Block
12 Arm Curl Stand
13 Leg Developer
14 Backrest Support
15 Seat Pad
16 Backrest Board
17 Arm Curl Pad
18 Sliding Block Lock Knob
19 Foam Roll
20 Foam Tube
21 Cross Bracket
22 End Cap
23 End Cap
24 End Cap
25 End Cap
26 Lock Pin
27 End Cap
28 Sleeve
29 Sleeve
30 Base Cap
31 Lock Knob
32 Olympic Sleeve
33 Bushing
34 Bushing
35 Rubber Bumper
36 Bushing
37 Cover Cap
38 Axle
39 Spring Clip
7 Tunturi Pure Strength
SIZE
Ø 75mm x 145mm
110mm x 38mm
25mmx 25mm
Ø 25mm
Ø 19mm
38mm x 38mm
M8
30mm x 50mm
40mm x 50mm
40mm x 60mm
M18
Ø 25mm x Ø10mm
Ø 50mm x Ø16mm
Ø 30mm x 30mm
Ø 18mm x Ø14mm
M10
Ø16mmxM10x56mm
Ø 24.5mm
www.tunturi-fitness.com
QUANTITY
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
6
3
2
4
1
6
2
1
1
2
2
6
1
1
6
2
1
2
26
1
1
