1. Items supplied (Fig. 1 / 2)
Item Description
1 Spirit level
2 Separator
3 Washer 8,4
4 Hexagonal head screw M 8x10
5 Fastening plate
6 12 mm wall plug
7 Washer 8.4
8 Hexagonal head wood screw
9 Anti-vibration rubber
10 Hexagonal nut with shoulder M8
11 Hexagonal head screw M8x25
12 Washer 8.4
13 Mounting rail
14 Folding arm

2. Technical data

Outreach, approx.
Arm adjustment, approx.
Load capacity, max.
3. Assembly
Fig. 3: Press the spirit level (1) into the mounting
rail (13).
Fig. 4 / 5: Screw the arm (14) to the mounting rail
(13). Use the fastening plate (5), washer (3) and
hexagonal head screw (4) for this purpose.
Fig. 6: Press the spacer (2) into the mounting on
the rear of the arm (14).
Fig. 7: Slide the anti-vibration rubbers (9) on to
the arm (14) so that they fit together with the
mountings on the outdoor air-conditioning
system. Secure the outdoor air-conditioning unit
using the hexagonal head screw M (11), washer
(12) and hexagonal nut with shoulder (10). Note:
Fig. 7 shows the screw connection without the
outdoor unit.
17.10.2007 15:21 Uhr Seite 5
4. Instructions for wall mounting
Quantity
a) Use only suitable fastening material.
1
2
2
2
2
3
3
3
4
b) Make sure that there are no electric cables or
4
4
4
1
2
430 mm
350 - 760 mm
140 kg
The supplied plugs (6) and screws (8) are
suitable for concrete, natural stone with a dense
structure, solid bricks, solid lime-sand blocks,
solid blocks made of lightweight concrete, pore
concrete (gas concrete), solid gypsum panels,
perforated high blocks, perforated lime-sand
blocks and hollow blocks made of lightweight
concrete.
other installations (for example water pipes) near
the drill holes. Ensure that the bracket is firmly
and horizontally fitted to the wall. The spirit level
integrated in the mounting rail will help you
ensure this.
