THMS 1
UNIVERSAL TABLET HOLDER WITH MUTLIFUNCTIONAL BRACKET
SAFETY INFORMATION
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the
equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations).
Make certain that wall mounts are properly installed and secured. Make certain that the
equipment is installed securely and cannot fall down.
7. During installation, observe the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sourc-
es of heat. Make certain that the equipment is always installed so that is cooled sufficiently
and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. Do not use this equipment in the immediate vicinity of water (does not apply to special out-
door equipment - in this case, observe the special instructions noted below. Do not expose
this equipment to flammable materials, fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place con-
tainers filled with liquids, such as vases or drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufac-
turer.
15. Do not open or modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g.,
due to tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause prop-
erty damage and personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the
equipment or if it has been damaged in another way, switch it off immediately and unplug
it from the mains outlet (if it is a powered device). This equipment may only be repaired by
authorized, qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please
separate plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
IMPORTANT:
Attach the THMS 1 tablet holder to a suitable stand with sufficient load bearing capacity.
During installation, keep hold of the tablet until you have checked all supports, clamps and
fixing nuts are positioned correctly and tightened.
MANUFACTURER'S WARRANTY & LIMITATION OF LIABILITY
You can find our current warranty conditions and limitation of liability at: https:/ /cdn-shop.adam-
hall.com/media/pdf/MANUFACTURERS-DECLARATIONS_ADAM_HALL.pdf
To request warranty service for a product, please contact Adam Hall GmbH, Adam-Hall-Str. 1,
61267 Neu Anspach / Email Info@adamhall.com / 49 (0) 6081 / 9419-0
PROPER DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste separation)
This symbol on the product, or the documents accompanying the product, indicates that this ap-
pliance may not be treated as household waste. This is to avoid environmental damage or person-
al injury due to uncontrolled waste disposal. Please dispose of this product separately from other
waste and have it recycled to promote sustainable economic activity.
SPECIFICATIONS
Product number THMS1
Product type Stands and Tripods
Type Tablet & Smartphone Holder
Mounting Clamp connector
Suitable for tube diameter 10 - 35 mm
Minimum device size 7.9 "
(screen size)
Maximum device size 12.9 "
(screen size)
Maximum device depth 15 mm
Material Plastic
Color Black
Features Portrait and landscape format, Tilt and swivel
Accessories (included) Adapter for square tube or table mounting included,
Power bank mounting bracket included
(range 60 - 100 mm)
Weight 0.42 kg
Adam Hall GmbH | Adam-Hall-Str. 1 | 61267 Neu-Anspach | Germany
Phone: +49 6081 9419-0 | adamhall.com
FEATURES
• Suitable for all tablets with 7.9" to 12.9" screens and a maximum depth of 1.5 cm.
• Suitable for all iPad models , Galaxy Tab, Microsoft Surface Pro etc.
• Ball joint for ultra-flexible positioning and 360° turning
• Sturdy, robust design with built-in power bank receptacle
• Includes adapter for square-section tubes
• Includes multifunctional receptacle as power bank repository or smartphone holder
INTRODUCTION
The THMS 1 is suitable for all standard tablets with screen sizes from 7.9 to 12.9
inches and can be easily attached to all round stand poles with a diameter of up to 35
mm and square-section tubes with a diameter of up to 25 mm. Adjustable arms keep
your tablet stable and secure. The clever ball joint design is extremely flexible, enabling
positioning for the perfect viewing angle. The durable, light design includes a useful,
adjustable receptacle that can be used as a power bank repository or attached to the
ball joint as a smartphone holder.
PART DESCRIPTION
4
5
5
Wing nut to clamp the tablet holder to a stand.
1
To attach the holder to a square tube, table edge or small diameter tube,
2
insert the wedge-shaped adapter into the 90° angled recess of the rigid clamp jaws
(adapter included for small diameter tubes).
Clamp device with wing nut for flexible adjustment of tilt angle, rotation to portrait or
3
landscape (360° rotation) and for pivoting the tablet (180°).
Clamp lever for adjustment of holding arms to suit tablet width.
4
Rotating support brackets.
5
Clamp lever for adjustment of holding arms to suit tablet height.
6
Spring clamp (2 x).
7
Removable mounting bracket for power bank.
8
Clamp lever for adjustment to required size (range 60-100 mm).
9
7
2
6
3
1
9
8
