Name
.
IR receiver
5
.
Front panel lock
6
.
Live button
7
.
Playback buttons
8
.
PTZ buttons
9
.
Direction
10
Enter button
TVR 45HD Quick Start Guide
Description
Event Alarm: A flashing red light indicates that there is a sensor
another alarm such as motion or tampering. No light indicates that there is no
alarm.
HDD: HDD indicator blinks red when data is being read from or written to the
HDD. A steady red light indicates an HDD exception or error.
Tx/Rx: Steady green indicates a normal network connection. No light indicates
that it is not connected to a network.
Technical Alarm: A steady red light indicates that there is a technical alarm from
the recorder. No light indicates that there is no alarm.
Receiver for IR remote.
To connect the remote control to the recorder, press the Device button, enter the
device address, and press Enter. See "
information.
You can lock or unlock the front panel with a key. It provides access to the
HDDs.
Switch to live view mode.
Reverse: In live view mode, use to play back the earliest video. In playback
mode, playback a camera in the reverse direction.
Pause: In live view mode, freeze the last image of the live display for all active
cameras displayed. In playback mode, stop playback.
Play: In live view mode, play all day playback of the current camera (upper-left
video tile if in multiview mode). In playback mode, play back a camera in the
forward direction. In search mode, play back a selected video or view a
snapshot. In PTZ mode, do an auto tour.
Replay: In playback mode, start playing the current file. Starts at the beginning of
the file.
Zoom +/-: In live view mode, playback mode, and PTZ control mode use this
button to zoom in and out. Also use them to navigate within menus.
Preset: In PTZ control mode, press Preset and a numeric button to call the
specified preset.
Also use to edit holiday mode, video search mode, HDD selection mode, user
management mode, bookmark management, and bookmark search.
Tour: In PTZ control mode, press Tour and a numeric button to call the specified
shadow tour.
Also use to scroll between calendar months and to navigate in a text field.
The DIRECTION buttons are used to navigate between different fields and items
in menus.
The ENTER button is used to confirm selection in any of the menu modes.
IR remote control
" on page 5 for more
Alarm In
or
3
