1. Programming the first transmitter
OK
x1 BIP
x2 BIP
x2 BIP
After correct programming
the tubular motor will make 6 short
beeps (6xBIP) and it is ready
to regular using.
Press the "UP" button and you
Turn on the power, 2 short In an interval of about two
beep will be heard immediately seconds, press the "P2" button
will hear an acoustic signal
(2xBIP).
twice and you will hear an
(x1 BIP)
acoustic signal (x2 BIP)
2. Programming the direction of movement
OK
x1 BIP
x2 BIP
x2 BIP
After correct programming
the tubular motor will make 6 short
beeps (6xBIP) and it is ready
to regular using.
Press the "DOWN" button and
Turn on the power, 2 short In an interval of about two
beep will be heard immediately seconds, press the "P2" button
you will hear an acoustic signal
(2xBIP). twice and you will hear an
(x1 BIP)
acoustic signal (x2 BIP)
3. Setting the limit swiches
1. Start the closing mode of the shutter until it stops in the requested position
(if the roller shutter is fully closed and the motor is still working, it should be stopped and proceed to step 3).
2. Regulate the knob (marked ⇧ ) in the (+) direction set the requested position of the shutter.
3. Raise the shutter and regulate the knob in the (-) direction and repeat the procedure if the requested position is crossed.
1. Start the opening mode of the shutter until it stops in the requested position
(if the roller shutter is still opening and the motor is still working it should be stopped and proceed to step 3).
2. Regulate the knob (marked ⇩ ) in the (+) direction set the requested position of the shutter.
3. Raise the shutter and regulate the knob in the (-) direction and repeat the procedure if the requested position is crossed.
