Remote controllers
description
P2
DC 305 DC 306
UP
K+
DC 230
STOP
K-
DOWN
DC 920
DC 313
DC 317 DC 448
DOWN
OK
MODE P2
DC 315 DC 316
K1
K2
Activation of the "P2" button
in remote controller DC315 and DC316
is performed by a combination
of both keys "STOP" and "UP".
DC 287 DC 289
UP
K+
STOP
K-
DOWN
P2
DC 288
DC 559
UP
STOP
To program the clock and the date coder,
please hold "MODE" button for 4
UP
seconds until the numbers on the
display will flash. Change the numbers
STOP
using the "UP" & "DOWN" button and
DOWN
press "MODE" button, if all the settings
are set up please press "OK" button.
LEGEND :
UP - activation of this button will move roller shutter up
DOWN - activation of this button will move roller shutter down
P2- activation of this button will bring the tubular motor
in to programming
K+ - activation of this button will switch to the next channel
K- - activation of this button will switch to the previous channel.
K1 –buttons of channel one
K2 –buttons of channel two
MODE – button which activates the settings of clock and date coder
P2
DC 250 DC 251
DC 229 DC 230
K1 K2
P2
DC 661
UP
STOP
STOP
DOWN
MODE P2 OK
- 7 -
P2
DC 1700
UP
K+
STOP
K-
DOWN
DC 1770
UP
STOP
DOWN
KEYS
UP
UP LOCK
DC 61
STOP
DOWN
Activation of the "P2" button
in remote controller DC115A and DC61
is performed by a combination
of both keys "STOP" and "UP".
DC 1702
UP
STOP
DOWN
K+
K-
DC 1771
UP
STOP
DOWN
K1 K2
P2
DOWN
DC 115A
KEYS
LOCK
