Installation
GB
INSTALLATION
• This grill uses 2,500 watts at maximum position.
Therefore, before connection, ensure that your
electricity supply is fitted with a minimum 16-
ampere fuse. IT IS VITAL that your grill be
connected to earth.
• It is likewise necessary to provide a bipolar cut-off
device in your power supply circuit, where the
opening of the contacts is more than 3 mm.
• The plug must be accessible after installation.
• If the supply lead is damaged, it must be replaced
by an equivalent lead (H07RNF 3x1,5mm²)
available from the after-sales department.
• Cooking with the grill necessarily involves the
emission of fumes. Sometimes, when cooking
meats with a great deal of fat, small flames will
appear, identical to those on a barbecue. It is
necessary to take this feature into account when
choosing a place to build in your grill.
FITTING
This grill is built into a work surface or kitchen unit by
simply cutting a hole the corresponding shape.
Any support may be suitable: brickwork, timber,
metal, granite, laminate, etc.
Dimensions of apparatus: 520 x 295 mm
Dimensions of hole cut in work surface: 490 x 270
mm
IT IS ABSOLUTELY IMPERATIVE TO LEAVE A
SPACE OF AT LEAST 5 CM BETWEEN THE
BOTTOM OF THE GRILL AND THE FIRST SHELF
OF THE KITCHEN UNIT.
THE DISTANCE BETWEEN THE WALL AND THE
REAR OF THE APPARATUS SHOULD BE 5.5 CM.
