Comet Spa DSG-10 EX Bedienungsanleitung Seite 21

Free spaces to be observed
For a safe and correct use and an easy maintenance
of the machine, it is advisable to install it in such
a position that observes the minimum distances,
expressed in millimetres, from the walls or big
obstacles shown in the picture.
ASSEMBLY AND PREPARATION
OF THE MACHINE
Preparation of the machine for its use
Upon receipt of the machine in the User's factory,
follow the instructions described below for its
correct positioning:
- unpack the machine and remove its protection
wrapping.
- lift the machine according to the instructions
and warnings described in Chapter "Handling
and transport of the machine".
- Install the machine in the desired place..
Preventive checks and controls
Upon receipt of the machine, it is advisable to:
- check if all the parts composing the machine
have been delivered to the User's factory,
- check overall condition of the complete device,
in particular:
- check that the electric panel board is
undamaged;
- check that the main switch is undamaged.
Carefully check if the protective wrapping is visibly
torn.
Cleaning and lubrication of the machine
The power cord supplied with the machine is plugged
by the Builder. It must be connected to the main
supply line after checking that the voltage and the
power supply frequency of the motors and electric
components correspond to the voltage and power
supply frequency available in the User's factory.
WARNINGS
- Check that the User's power supply voltage
corresponds to the one indicated on the machine
rating. On the contrary, contact the Builder.
- In compliance with the regulations in force,
the User will have to provide the machine
with safety devices, to avoid short-circuits and
overloads, in order to protect the machine
power supply line.
- Only qualified engineers can connect the
machine to the power sources.
Adjust the temperature
Adjust the temperature by means of the
thermoregulator situated on the control panel.
This machine is equipped with an electronic
thermoregulator to check and adjust the boiler
temperature (=pressure) from min. 3 BAR to max. 10
BAR.
Then press ③+ to increase the temperature or press
③- to decrease it to modify the temperature.
- When turning on the unit, the display shows the
total working hours ( 10 hours for 1 number).
- After few seconds, the display shows the
working temperature.
- It is possible to set the temperature in Celsius
°C or Fahrenheit °F pushing together buttons
③+ and ③-
until the new mode; after few seconds it will be
recordered.
- Pushing for the first time one of the two
buttons ③+ or ③-
allows to set the temperature, the display lights
start flashing, showing the last recordered
temperature; pushing again ③+ button
increase the temperature (one degree per
time), pushing again ③- button decrease the
temperature (one degree per time)
- After 4 seconds the temperature is recordered,
then, the display stop its flashing, returning to
show the working temperature.
21
EN
