ACCESSORI IN DOTAZIONE
a)
N°4 PROFILI IN ALLUMINIO PER LA CORNICE DEL T ELAIO,
b)
N° 25 CURSORI;
c)
T ELA PER LA PROIEZIONE;
d)
N°4 AST E IN FERRO (T ONDINO);
e)
N°4 PIAST RE ANGOLARI PER IL FISSAGGIO DELLA CORNICE;
f)
N°16 VIT I E BULLONI PER FISSAGGIO ANGOLARI;
g)
N°2 SUPPORT I PER L'INST ALLAZIONE A PARET E;
DISIMBALLO DELLO SCHERMO
Assicurarsi che nessuna parte dello schermo sia stata danneggiata durante il trasporto. Verificare che siano presenti tutti gli accessori dello schermo descritti
sopra. Attenzione: si raccomanda di non usare taglierini o oggetti appuntiti per aprire l' imballo contenente la tela per la proiezione!!
ISTRUZIONI PER IL MONTAGGIO
1 – infilare i cursori nei singoli profili nella quantità indicata nello schema sotto, nell'imballo si trovano 4 profili, 2 basi + 2 altezze. FIG.1
2 – preparare i 4 angolari inserendo vite e bullone senza stringerli. FIG.2
3 – unire i profili con gli angolari formando la cornice. FIG.3
4 – inserire i tondini nelle asole della tela. FIG.4
5 – montare il tessuto sulla cornice con gli appositi elastici. FIG.5
L' INSTALLAZIONE DELLO SCHERMO:
L'installazione può avvenire solo su una superficie verticale (muro, parete divisoria ecc.) tramite le due piastre che si trovano nell'imballo. Dopo aver montato lo schermo,
calcoliamo la distanza di fissaggio delle due piastre considerando che la distanza fra l'angolo della cornice e la piastra (vedi figura 6 misura A), fissare a parete i supporti
facendo attenzione ad utilizzare viti e tasselli adeguati alla parete che si utilizza per il fissaggio e al peso dello schermo. Dopo aver montato i due supporti agganciare lo
schermo come indicato nelle figure 7
AVVERTENZE E PRECAUZIONI !
Si ricorda che per una maggiore sicurezza di tenuta, soprattutto in caso di installazione prolungata nel tempo, è consigliata un' ispezione periodica degli elastici
che potrebbero per motiv i fisici deteriorarsi nel tempo.
ATTENZIONE!! L'azienda produttrice non si assume responsabilità per danni, a cose o persone, causati da uso
improprio dello schermo.
ACCESSORIES PROVIDED
a)
N° 4 ALUMINUM PROFILES FOR T HE FRAME OF T HE SCREEN,
b)
N° 25 SLIDE FAST ENERS;
c)
PROJECT ION CLOT H;
d)
N° 4 IRON RODS (ROUND BARS);
e)
N° 4 CORNER PIECES FOR AT T ACHING T HE FRAME;
f)
N° 16 SCREWS AND BOLT S FOR AT T ACHING T HE CORNERS;
g)
N° 2 SUPPORT S FOR WALL INST ALLAT ION;
UNPACKING THE SCREEN
Make sure that no part of the screen has been damaged during transport. Check that all the screen accessories described abov e are present. Attention: We
recommend that box cutters or sharp obj ects not be used to open the package containing the proj ection screen!!
ASSEMBLY INSTRUCTIONS
1 – slide the slide fasteners onto the individual profiles in the number shown in the diagram below; in the package, you will find 4 profiles, 2 bases + 2 uprights. FIG.1
2 – prepare the 4 corners by inserting screw and bolt without tightening them. FIG.2
3 – join the profiles with the corners, forming a frame. FIG.3
4 – insert the round bars in the slots in the cloth. FIG.4
5 – assemble the fabric on the frame using the elastic bands provided FIG.5
SCREEN INSTALLATION:
It can only be installed on a vertical surface (wall, dividing panel, etc.) using the two plates contained in the package. After having assembled the screen, calculate the fix ing
distance of the two plates, taking into consideration the distance between the corner of the frame and plate (see figure to the right of measurement A); attach the supports to
the wall taking care to use screws and anchors suitable for the wall that you are attaching to and the weight of the screen. After having mounted the two supports, hook the
screen as shown in the figures below 7.
WARNINGS AND PRECAUTIONS!
Remember that, for a safer attachment, and especially in the case of a prolonged installation ov er time, we recommend that you periodically inspect the elastic
bands, which can physically deteriorate ov er time.
ATTENTION! The manufacturer assumes no responsibility for damage or personal inj ury caused by the improper
use of the screen.
