PRODUCT INFORMATION
MediGunPRO by Casada is a wireless, state-of-the-art massage device that helps to reduce muscle sore-
ness and tension, promote blood circulation, optimize mobility and improve the general condition of the
body's musculoskeletal system.
SPECIFICATIONS | TECHNICAL DATA
1
2
1
MediGunPRO advanced technology with powerful brushless High-Torque Motor
2
Interchangeable head attachments (x6) – Fork, Bullet, Flat, Ball, Trapeze, Wave
3
Rechargeable Lithium-Ion battery (More than 4 hours using time when fully charged)
4
Speed level
5
Mode
6
Increase speed
7
Decrease speed
8
Battery power
9
Adapter port
10
ON|OFF switch
TECHNICAL DATA
Article number:
CMK-149
Measurements:
17cm x 21,8cm x 6,3cm
Frequency :
Level 1 – 30 Hz 1800 pressure impulses/min | Level 2 – 36 Hz 2200 pressure
impulses/min | Level 3 – 43 Hz 2600 pressure impulses/min | Level 4 – 50 Hz
3000 pressure impulses/min | Level 5 – 56 Hz 3400 pressure impulses/min
Weight:
1,1 kg
Voltage:
110 – 240 V, 50 / 60 Hz – 5A, 26 V – DC – 1A
Adapter :
Input : AC 100-240V, 50/60Hz, 0.3A
Output : DC 26V, 1A
Device:
6x Built-in Lithium Battery
DC 21.6 V, 2600mAh
Certificates:
6
4
5
1.8mm
1.8mm
6
尺寸：20.36x5.7mm
7
3
9
8
10
USAGE INSTRUCTIONS
PLEASE READ PRIOR TO USE
CHARGING
•
Please fully charge up to six hours when first use.
•
When charging, connect the DC end of the supplied 26 V adapter to the battery's charging port and
plug AC side cable into wall outlet, then turn the power switch to the ON position to charge. Once the
battery is fully charged, unplug the power cord and turn off the unit for 3 seconds to continue using the
MediGunPRO.
•
The LED light flashes to indicate the battery level and indicating it is charging.
•
When all LED stop flashing and remain lit, it indicates that the battery was fully charged.
•
Battery can be recharged at any time and at any battery level.
•
It is not recommended to fully deplete the battery to the red LED level.
•
This device average run-time is about 2 hours depending on speed level and pressure applied during
using.
Attention: The MediGunPRO cannot be used during charging.
OPER ATING
1.
Turn the power switch on the bottom of the battery to the "ON" position to start the power. Turn the
power switch to the „OFF" position to turn off the power.
2.
Press the Mode button when the unit is turned on. The MediGunPRO then starts in manual mode, which
you can adjust with the „–/+" buttons. Press the mode button again to switch to automatic mode, which
can also be adjusted using the „–/+" keys. In automatic mode, the speed changes from fast to slow in
5-second intervals.
3.
Massage desired body part at the desired speed applying pressure as needed.
4.
With power off, you can change the massage head and pull it out by hand.
M AINTENANCE, CLEANING & STOR AGE
•
Use a slightly damp towel to clean device and a dry with a soft cloth.
7
