perfetta connessione fra la sonda ed il modulo.
3) Il primo reintegro, in caso di livello basso, verrà effettuato dopo 5 minuti dall'ac-
censione del Controller.

DATI TECNICI

Modello 2010-08
Allacciamento alla rete: 110 – 240 volts
Consumo : 15 W max (pompa in funzione)
Parti di ricambio:
ROS006: sensore di livello
RMI001: pompa a bassa tensione
RELTRASF: trasformatore di ricambio
50 – 60 Hz
SIGNALS
RED LED: LEVEL ALARM
- No RO water
- The pump may be damaged or clogged
- The tube may be blocked
If none of the abnormalities described above have occurred, please send the controller to
an ELOS repair center.
Note: the occurrence of one of the states listed above will trigger the RED alarm LED ONLY
after 2,5 hours from the start of the system.
GREEN LED: CORRECT OPERATION
flashing quickly: at starting and for the next 5 minutes
light on: the level is correct
Flashing slowly: the level is low, the controller performs the necessary top-ups (every 15 min.)
YELLOW LED: PUMP OPERATION
light on: the pump is running
HOW TO USE THE PUMP
Simply pressing the "M" button will activate the pump. This function is very useful for making
small additions, mixing additives with RO water or filling an extra container of RO water. DO
NOT USE THE PUMP WITH LIQUID OTHER THAN RO WATER.

WARRANTY

The device is covered by a two-year warranty against breakdown due to manufacturing de-
fects. The warranty does not covers damages caused by improper use.
Opening the controller case or modifying the OSMOCONTROLLER in any way voids the Elos
warranty.
NOTES
1) When you turn the device ON it performs a test loop that allows the user to do a visual
verification of the correct operation of the elements of the circuit: the LED will light up in suc-
cession for a short time, then the pump will run for a short period. Verify that all components
are operating properly.
3) No alarm will be activated if the Sensor is not properly connected. The controller regularly
verifies that there is a proper connection of the sensor to the control module.
4) The first top up, in case of low level, will be made after 5 minutes after the Controller is
switched on.
TECHNICAL DATA
Model 2010-08
Mains connection: 110 to 240 volts from 50 to 60 Hz
Consumption: 15 W max (pump running)
Spare Parts:
ROS006: level sensor
RMI001: low voltage pump
RELTRASF: transformer parts
