INFOSEC UPS SYSTEM Z4 BusinessBox Bedienungsanleitung Seite 8

1 0 . T E C H N I C A L S P E C I F I C A T I O N S
TECHNOLOGY
Technology
Power
Output form
Protection
Power factor
PHYSICAL CHARACTERISTICS
Dimensions
DxWxH
Weight kg
Output connectors
INPUT TECHNICAL CHARACTERISTICS
Voltage
Voltage range
OUTPUT TECHNICAL CHARACTERISTICS (battery mode)
Voltage
Voltage regulation
Frequency
TRANSFER TIME
Typical
INDICATORS
AC mode
Battery mode
Low battery at battery mode
Fault
Battery weak at AC mode
Battery fault at AC mode
AUDIBLE ALARMS
Battery mode
Low battery at battery mode
Fault
Battery weak at AC mode
Battery fault at AC mode
BATTERY
Battery number & type
Backup time
(*depending on the backup time)
Recharging time
ENVIRONMENT
Ideal Environment
NORMS
Security / Standard
INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
8
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 07 09 AA 04 205 20
BusinessBox 500
Discharge / overcharge / overload + phone/ADSL line protection
(mm)
2 French or German backup time outlets / RJ11 (In/Out)
3 IEC backup time outlets / 1 IEC surge protected outlet /
0-40°C, 0-90% of relative humidity (without condensation)
High Frequency (microprocessor controlled)
450 VA
Modified Sinewave
0,45
185 x 80 x 230
2,5
RJ11 (In/Out)
220/230/240 V
170/280 V
220 V
± 10 %
50 or 60 Hz ± 1 Hz (auto frequency)
Green LED lighting
Green LED flashing every 4 seconds
Green LED flashing every second
Red LED lighting
Red LED flashing every 2 seconds for 30 seconds
Red LED flashing 3 times every 2 seconds
Sounding every 4 seconds
Sounding every second
Continuously sounding
Sounding every 2 seconds for 30 seconds
Sounding 3 times every 2 seconds
12V/4.5Ah x 1 pc
Up to 10 min*
16 hours to 90% after complete discharge
BusinessBox 700
600 VA
0,5
3,1
2-6 ms
12V/7Ah x 1 pc
Up to 20 min*
CE
