If your audio system includes speakers that are large enough to reproduce bass or if you listen at low levels, you can
get fuller bass response by disengaging the special bass filter after performing the setup procedure. Press and hold
the Bass button to deactivate the filter (the SUB indicator will be lit). To reactivate the filter, press and hold the Bass
button again (the SUB indicator will turn off). Choose the bass filter setting that you prefer.
Setup Procedure for Systems with an Aftermarket Powered Subwoofer:
IMPORTANT! We recommend always performing the setup procedure with the filter engaged (SUB
indicator off).
1. Set your subwoofer's crossover (low-pass filter) to 50Hz.
2. Turn your subwoofer's volume control down until you can barely hear that the subwoofer is playing while you're
seated in the driver's position.
Set subwoofer
volume to
barely audible
Set subwoofer
low-pass crossover
to 50Hz
3. Perform the MS-2's setup procedure as directed on page 4.
4. Press and hold the BASS button to disengage the MS-2's special bass filter (the SUB indicator should be off during
setup).
5. When the setup procedure is completed, readjust your subwoofer's volume control to suit your preference. Then,
use the MS-2's adjustments to further fine tune the sound.
If you want to perform a setup procedure again, press and hold the BASS button to re-engage the filter and repeat
steps 1 and 2 before doing so.
If you want to use the MS-2 in another system that doesn't include a powered subwoofer, press and hold the MS-2's
Bass button for five seconds to return it to normal operation. The SUB indicator will turn off.
0290CSK - JBL MS2 OM EN v1.indd 5
Standby and On Modes
The MS-2 will automatically enter Standby mode whenever no control buttons have been pressed and an audio
signal has not been present for approximately five minutes. All indicators will be off and the Power indicator will
pulse red. The MS-2 will automatically turn on whenever an audio signal is present at its input or whenever you
press any control button.
To avoid draining the vehicle's battery, you should disconnect the MS-2's power supply from the car's 12V power
port when you aren't using the MS-2 and the car won't be driven for a few hours.
Setting the System Volume
For the best audio performance, set your portable music player's volume to the same level it was during the setup
procedure, and use your vehicle audio system's volume control to adjust the volume. If you hear distortion in your
system after performing the MS-2's setup procedure, turn your portable audio player's volume down a little to
eliminate it.
Adjusting the Sound
Press the Treble, Impact, Bass and Image buttons to fine-tune the sound to your personal preference. The indicators
next to the buttons will show the settings.
Setting Memory
The MS-2 's settings are stored in flash memory, and will remain indefinitely when The MS-2 's power connection
is removed.

sPecIFIcatIOn

Maximum audio signal input voltage:
MS-2 Power supply voltage requirement:
MS-2 Power connector voltage output:
USB Charger connector voltage output:
Dimensions (H x W x D):
Weight:
1.3V
10.5V – 14.4V DC
6V DC @ 100mA
5V DC @ 500mA
5-1/4" x 2-7/8" x 13/16"
(133mm x 73mm x 21mm)
0.2 lb (96g)
