ENGLISH
6
PRODUCT FEATURES – PAGE 3
Articles (included in set)
1
RUNPOTEC RT 2008 incl. clamping mechanisms
2
Pluggable attachment Ø 40 mm
3
Pluggable attachment Ø 32 mm
4
Pluggable attachment Ø 25 mm
5
Pluggable attachment Ø 20 mm
6
Pluggable attachment fl exible socket
7
Pluggable coupling + belt clip – set
8
RUNPOTEC system case with RT 2008 case insert
9
RUNPOGLIDER spiral MET (metal spiral) – 15 m
Accessories (not included in set)
Pluggable attachment socket rigid 90°
10
(also suitable for tube Ø 20 mm)

SAFETY INFORMATION

The RT 2008 can only be operated with the RUNPOGLIDER spiral MET! Never use the
RT 2008 near live wires – the RUNPOGLIDER spiral MET (metal spiral) is electrically
conductive! Caution risk of fatal injury!
INTRODUCTION
Thank you for purchasing this RT2008 – insertion tool for RUNPOGLIDER spiral MET by
RUNPOTEC. These operating instructions describe the safe use of your RT2008. Read
the instructions for use thoroughly before commissioning. If you have any questions
about commissioning, assembly, safety and applications, or problems, please con-
tact your dealer or RUNPOTEC by telephone or e-mail. You will find our contact data
on page 2. Application videos on www.runpotec.com
APPLICATION
A
II I
I. Push on and rotate the pluggable coupling!
II. Fit the fl exible socket pluggable attachment.
C
Attention!
electric
conductive
Thread the RUNPOGLIDER spiral MET
(metal spiral) in or through.
All images are representative. Changes and printing errors excepted.
STRONGEST CABLE PULLING
Item no.
20004
20040
20032
20025
20020
20010
20333
20611
30018
20253
B
I
Push on the red locking rings (I and II).
D
I
II
Push the red locking rings (I and II)
to close.
www.RUNPOTEC.COm
E 1
Insert the pluggable attachment into
the tube end.
F
Press the pushbutton until it latches
(CLICK!).
ROTATION FUNCTION
If you hit an obstacle that cannot be
overcome through normal pumping,
enable the rotate function, which ad-
ditionally causes the spiral to rotate, in
order ot overcome even troublesome,
problematic points.
B
Turn the clamping handle clockwise to
clamp. The spiral is axially clamped.
II
SPECIAL FUNCTION
As of a pipe length of 20 m we recom-
mend the additional use of a cordless
screwdriver to overcome the problem
areas more easily.
Rotate the spiral with the cordless
screwdriver clockwise only.
I.
Clamping handle open
II. Keep spiral tensed.
III. Optimum speed: 800–1200 rpm.
RUNPOTEC GmbH – Irlachstrasse 31 – A-5303 Thalgau
Tel.: +43-6235-20 335 – Fax: DW 35 – office@runpotec.com
ENGLISH
E 2
I II
Push in the tube (I) up to the stop and
secure with the red clamping ring (II).
G
Pump to push in the RUNPOGLIDER
spiral MET.
A
Fully extend the elescopic tube.
C
Turn and advance the ratchet
alternately several times.
I
II
III
