Using effects
06: Hum Noise Cut
Parameter name
Frequency
Depth
Low Gain
High Gain
Level
07: Reverb
Parameter name
Type
Time
Balance
Low Gain
High Gain
Level
08: Int-Mic Rec.
Parameter name
Type
Low Gain
High Gain
Level
09: Ext-Mic Rec.
Parameter name
Type
Low Gain
High Gain
Level
10: Mastering
Parameter name
Clarity
Crossover
Low Compress
High Compress
Low Gain
High Gain
Level
50
Range of values
50Hz, 60Hz
0–80–100
-12dB–0dB–+12dB
-12dB–0dB–+12dB
0–80–100
Range of values
Hall, Room, Plate
1–50–100
D100:0W–D50:50W–
D0:100W
-12dB–0dB–+12dB
-12dB–0dB–+12dB
0–100
Range of values
1–5
-12dB–0dB–+12dB
-12dB–0dB–+12dB
0–80–100
Range of values
1–5
-12dB–0dB–+12dB
-12dB–0dB–+12dB
0–80–100
Range of values
1–50–100
200Hz, 250Hz, 315Hz,
400Hz, 500Hz, 630Hz,
800Hz, 1kHz, 1.25Hz,
1.6kHz, 2kHz
0–50–100
0–50–100
-12dB–0dB–+12dB
-12dB–0dB–+12dB
0–80–100
Explanation
Specifies the frequency at which hum will be cut.
Adjusts the amount by which hum will be cut.
Adjusts the low-range gain.
Adjusts the high-range gain.
Adjusts the output volume.
Explanation
Selects the type of reverb.
Adjusts the length of reverberation.
Adjusts the proportion between the original sound
and the reverberation.
Adjusts the low-range gain.
Adjusts the high-range gain.
Adjusts the output volume.
Explanation
Selects the type of transformation.
Adjusts the low-range gain.
Adjusts the high-range gain.
Adjusts the output volume.
Explanation
Selects the type of transformation.
Adjusts the low-range gain.
Adjusts the high-range gain.
Adjusts the output volume.
Explanation
Adjusts the amount of clarification applied to the
sound.
Specifies the frequency at which the low- and high-
range compressors are divided.
Adjusts the amount of compression for frequencies
below the Crossover point you specified.
Adjusts the amount of compression for frequencies
above the Crossover point you specified.
Adjusts the low-range gain.
Adjusts the high-range gain.
Adjusts the output volume.
